Output Dimensions - Microtek ScanMaker 35T Plus User Manual

Ouput Dimensions
The output dimensions determine the width and height of your image when output to an
output device such as a monitor or printer. Take note of the following:
• The output dimensions can be changed only if the Aspect Lock is on.
• The output dimensions are calculated dynamically, and the system looks at other
variables such as your resolution and scaling to determine the final output
dimensions. This means that you may specify output dimensions of 5" x 7", but
because of intervening variables, the actual output dimensions may be 4.85" x 6.9"
— which is the closest the system can produce given your other variables.
Aspect
Lock is on
Input edit boxes
are grayed out
With Aspect Lock on, only output
dimensions can be edited
Reference 41
