LEM ITZ 2000-SB FLEX ULTRASTAB Manual

Current Transducer ITZ 2000-SB FLEX ULTRASTAB
For ultra-high precision measurement of current: DC, AC, pulsed..., with galvanic separation
between primary and secondary. Separate magnetic head and measuring electronics provides
high flexibility.
Features
● ±10 V voltage output
● Closed loop fluxgate
● Split design - separate head
and rack electronics.
● Analog output on 15-pin D-sub female output connector
● Status/interlock port on 9-pin D-sub male output connector
● Secondary current monitoring on BNC connector
● 4 mm banana sockets for secondary current output
● Full-featured indicator panel.
Advantages
● Very high accuracy
● Excellent linearity
● Extremely low temperature drift
● Wide frequency bandwidth
● High immunity to external fields
● No insertion losses
● Low noise on output signal
● Low noise feedback to primary conductor.
N° 88.24.69.100.0
2November2022/Version 5
Applications
● Feedback element in high-precision, high-stability power
● Calibration unit
● Absolute current standard reference
● Test and calibration of current sources
● Current extender for power systems
● Differential current measurement on power line
● Metrology applications.
Standards
EMC:
● EN 61000-6-2: 2019
● EN 61000-6-3: 2007 + A1 (2011)
● EN 61326-1: 2013
Safety:
● IEC 61010-1: 2010/AMD1: 2016.
Application Domains
● Industrial
● Laboratory
● Medical.
LEM reserves the right to carry out modifications on its transducers,
in order to improve them.
supplies
I
= 2000 A
P M
