- Page 1 Security IP CAMERA QUICK OPERATION GUIDE Apply for Model:P5-5X /P14-5X/ P2R-20X/P10-5X Note: Due to the continuous updating of the product and software, there may be a discrepancy between the operating guide and the APP interface. All the instructions are subject to the actual operation...
- Page 2 It would be better for us to improve our service efficiency if you can provide your email address, the model of the product, and the order number you purchased. Name der Firma: ShenZhen JideTech Development Co., Limited Firmenanschrift: 9F Niulanqian Building...
-
Page 3: Table Of Contents
Contents Security IP CAMERA................................... - 1 - Servicegarantie..............................错误！未定义书签。 1. Introduction....................................- 1 - 2. Installation....................................- 2 - 3. SD Card Slot....................................- 2 - 4. APP Download..................................... - 4 - 5. Mobile APP Connection................................- 4 - 5.1 POE Camera connection..............................- 4 - 5.2 Connect Hot-Spot................................ -
Page 4: Introduction
1. Introduction Thanks for buying JideTech Security IP Camera. We provide IP cameras which has different appearance and function. This manual describes all the parameters, functional structure, how to use, common problems and solutions for the camera in detail. This would help you know the camera quickly and use it easily. -
Page 5: Installation
2. Installation 3. SD Card Slot - 2 -... - Page 6 - 3 -...
-
Page 7: App Download
4. APP Download Download APP “CamHipro” from Google Play or Apple Store, or scan the QR Code to install. 5. Mobile APP Connection 5.1 POE Camera connection POE Camera connection, please turn to 5.5 and 5.6 to add the camera to the - 4 -... -
Page 8: Connect Hot-Spot
app. 5.2 Connect Hot-Spot Connect power supply and use your mobile device to search the camera’s Hot-Spot and connect the Hot-Spot. As the below picture. The camera will turn into the self-test mode after connect power supply. It will take about 15 seconds. 5.3 Add Camera Add your camera to ‘CamHipro’... -
Page 9: Connect Wi-Fi
Step 4 Step 5 Step 6 Step 7 Step 8 Step 9 5.4 Connect Wi-Fi Connect your camera with the your Router’s Wi-Fi follow the steps of the below picture Step 1 Step 2 Step 3 Step 4 - 6 -... -
Page 10: Connect The Camera By Scan Qr Code
5.5 Connect the Camera by Scan QR Code A) Connect the camera to the power supply and the camera would turn into self-test mode, which would take about 15 seconds. Open the ‘CamHipro’ APP. B) Add the camera by Scan QR code follow the below steps. Note: Please make sure that the camera has connected to the network. -
Page 11: Connect The Camera By Search Nearby Devices
5.6 Connect the Camera by Search Nearby Devices Connect the camera to the power supply and the camera would turn into self-test mode, which A） would take about 15 seconds. Open the ‘CamHipro’ APP. B） Add the camera by Search Nearby Devices follow the below steps. Note: Please make sure that the camera has been connected to router’s Wi-Fi. -
Page 12: App Function Introduction
5.7 APP Function Introduction 5.7.1 Video playback and download - 9 -... -
Page 13: Local Files, Device List And Add Other New Camera
5.7.2 Local files, device list and add other new camera Click to view the local file of different cameras.； click to change the camera device list；click to add a new camera. 5.7.3 Pre-set point and auto cruise (For PTZ) Click the camera into real-time monitor -- turn to next page -- preset position Number 1-16 means 16 points you want to set up Adjust the camera rotation to the first point you want to monitor on the app;... -
Page 14: Change Password
Cruise line Number for setting Number for auto cruise Number for stop the First cruise line 1-16 41 +transfer 41+ Setting the Second cruise line 17-32 42 +transfer 42 + Setting About the automatic tracking function： Guard position tracking Call 92 (Enable) Setting 92 (off) Cruise group tracking Call 93 (enable) - Page 15 - 12 -...
-
Page 16: Motion Detection
5.7.6 Motion Detection 5.7.7 Email setting 5.7.8 FTP setting - 13 -... -
Page 17: Video Setting And Audio Setting
5.7.9 Video setting and audio setting 5.7.10 SD card plan recording 5.7.11 SD card setting - 14 -... -
Page 18: Device Time Setting
5.7.12 Device time setting 5.7.13 Default setting - 15 -... -
Page 19: Computer Browsing Access
6. Computer Browsing Access 6.1 Search IP Camera Download Software from the website ( http://www.gentlen168.com/security-camera/info/898.html) or Mini CD in the package, open the file and install search tool in your computer. Click “next” to find IP camera. You can select Network Card to search IP Camera. 6.2 View Video by Browser Support IE, Google and Firefox browser, install ActiveX before view video. -
Page 20: Parameter Settings
Local manual recording. Video Recording playback: Click the playback, select the date and time, select the local playback or SD card playback, search the video files and double click on the file to play. PTZ control operation interface, control the camera to rotate horizontally and vertically. -
Page 21: SettingNetwork
Video: Set the video format, video coding, resolution, bit rate, max frame rate, key frame interval, bit rate control and image quality. OSD Set: Set time stamp, time show, camera name and name show in this interface. Image: Adjust the brightness, saturation, contrast, exposure parameter and set the WDR, Aemode, Imgmode, Intelligent night mode, IR LED Control, IRCut in this interface. -
Page 22: SettingAlarm
6.4.3 SettingAlarm Audio alarm: Enable this function. Need to connect a buzzer, turn on & adjust the volume, audio alarm can work well. Motion detection: There are 4 windows selections under Motion Detection. Select different windows to display different window positions. Drag the selected window to enlarge the window proportion. -
Page 23: Settings System
Timed record: Set the Record files duration, whether to open Record and stream. Email Setting: FTP Setting: Terminal: Set the cruise laps, select the centred while self-check on/off, close the alarm PTZ movement on/off and indicator display mode. 485Set: These cameras can’t support RS485. Multiple setting: In the same LAN, two or more of this series products from our company's, can be displayed on the same page via this Multiple Setting. -
Page 24: Video Management Software (P2P Client)
7. Video Management Software (P2P Client) Using Video Management software to view multiple cameras at the same time 7.1 Software installation Download from the website ( http://www.gentlen168.com/security-camera/info/898.html ) or Mini CD in the Package. Install it on your computer. 7.2 Add Camera A）... - Page 25 B） Click to Set an Area name (Like: office / home / factory… …), you also can modify and delete Area as picture showing below. C） Click “Search” to find IP Camera in the LAN, Select the camera click “add” to Add camera. D）...
-
Page 26: Frequently Asked Questions
E） Click Back to preview screen, Double-click the camera name in the device list to preview the screen in real time. Frequently Asked Questions - 23 -... - Page 27 Q1: Remote viewing, appear pause and delay phenomenon? A:1) Related to network data, it is recommended to adjust the HD mode to Smooth mode when watching, and the video file is still saved in HD mode. 2) Try to reduce the camera stream when view the video, reducing the stream may affect the quality of the image. 3) Remote viewing, the network recommends uploading network data up to 512KB/S.
- Page 28 Q12: Third party software: iSpy Software operation A: iSpy Add camera selection: Open the software click add object, Select the IP photographer, Click ONVIF to enter the user name and password. URL enter: http:// camera IP address / port 8080. Click on the next page to see the full URL, click add, finish! Q13: Can't connect to Optical Modem Wi-Fi router? A: Recommend to use Wireless router, Some Optical Modem with Wi-Fi router has some kind of restriction, Cause the...
- Page 29 - 26 -...
