Summary of Contents for Lumens LC-RC01
- Page 1 LC-RC01 Remote control panel (Remote Control Panel) User Manual - English [Important] To download the latest version of Quick Start Guide, multilingual user manual, software, or driver, etc., please visit Lumens https://www.MyLumens.com/support...
-
Page 2: Table Of Contents
Package Contents ....................2 Chapter 2 Product Overview ....................3 2.1 LC-RC01 adapter ......................3 2.2 LC-RC01 control box ....................3 2.3 Size ..........................4 Chapter 3 Instruction for installation ..................5 3.1 Secure the adapter to the media processor with screws and connect the DC power and USB. -
Page 3: Chapter 1 Package Contents
Chapter 1 Package Contents LC-RC01 Power Adapter (Appearance may vary depending on country/ region) M3 x4 Flat Head(x2) Quick Installation Guide English-2... -
Page 4: Chapter 2 Product Overview
DC power input connected to the recording system to this interface power input port Connecting to RJ45 network port of the control RJ-45 network port 2.2 LC-RC01 control box Front View Bottom Item Function Descriptions USB 2.0 port The USB flash disk can be inserted for backup Please refer to 4.1 Button function... -
Page 5: Size
2.3 Size LC-RC01U LC-RC01E North America EU Regulations Regulations English-4... -
Page 6: Chapter 3 Instruction For Installation
Chapter 3 Instruction for installation 3.1 Secure the adapter to the media processor with screws and connect the DC power and USB. LC100 / LC100N LC200 3.2 Use the CAT5e network cable for connection (the length shall not exceed 30 meters) CAT5e Network Cable English-5... -
Page 7: Pass A Cable Tie Through The Mounting Hole To Secure The Network Cable Onto The Lc-Rc01 Control Box
Pass a cable tie through the mounting hole to secure the network cable onto the LC-RC01 control box. Cable tie Install the control box on the wall English-6... -
Page 8: Chapter 4 Function Description
Recording; press again to stop record Red light flickering Error or failure during recording 6 times <Remark> All indicators turn into flickering blue light: LC-RC01 is not connected to the recording system. Please check the connection of the recording system. English-7... -
Page 9: Web
Disconnected 4.3.2 Macro Settings Log in to the web page, Click [Scenes] > [Macro] LC-RC01 [1~3] buttons correspond to Macro [1~3] Settings Function Descriptions Select a scene to be set. Each supports up to 9 sets of scene. -
Page 10: Chapter 5 Troubleshooting
Chapter 5 Troubleshooting This chapter describes problems you may encounter while using LC-RC01. If you have questions, please refer to related chapters and follow all the suggested solutions. If the problem still occurred, please contact your distributor or the service center. -
Page 11: Chapter 6 Safety Instructions
Chapter 6 Safety Instructions Always follow these safety instructions when setting up and using the LC-RC01 Remote Control Panel: 1 Operation 1.1 Please use the product in the recommended operating environment, away from water or source of heat 1.2 Do not place the product on a tilted or unstable trolley, stand or table. -
Page 12: Copyright Information
Lumens is a trademark that is currently being registered by Lumens Digital Optics Inc. Copying, reproducing or transmitting this file is not allowed if a license is not provided by Lumens Digital Optics Inc. unless copying this file is for the purpose of backup after purchasing this product.
