Digi MIL-170TRM Installation Manual

10base-fl to 10base-t media converter for digi's media conversion system

Advertisement

Quick Links

Media Converter for Digi's
Media Conversion System
MIL-
10BASE-T
170TRM
This guide includes the following:
"Introduction" on page 2
"Features" on page 2
"Installation" on page 2
"Indicators" on page 4
"Specifications" on page 4
MIL-170TRM
10BASE-FL to 10BASE-T
Thumbscrews
TP
ACT
MDI-X MDI
TP
LINK
Installation Guide
FX
10BASE-FL
ACT
FX
TX
RX
LINK
Doc #: 90000096 Rev. A

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MIL-170TRM and is the answer not in the manual?

Questions and answers

Summary of Contents for Digi MIL-170TRM

  • Page 1: Installation Guide

    MIL-170TRM 10BASE-FL to 10BASE-T Media Converter for Digi's Media Conversion System MDI-X MDI MIL- 10BASE-T 170TRM Installation Guide This guide includes the following: “Introduction” on page 2 “Features” on page 2 “Installation” on page 2 “MDI-X/MDI Switch” on page 3 “Link Sentry Configuration”...
  • Page 2 “MIL-170,” MIL-170TRM,” and “converter” are used throughout this document to describe the MIL-170TRM. I ntrod uct i o n The MIL-170TRM is one of a series of modules designed to be installed into Digi's Media Conversion System. This half-/full-duplex device converts optical signals to electrical and vice-versa.
  • Page 3 3 to 1, and 6 to 2) L in k S e nt r y Configura t i on The Link Sentry feature on the MIL-170TRM is configured through a 4-position DIP switch (refer to Figure 1). Default setting for the DIP switches: All switches are in the “up”...
  • Page 4 • Pin 1 = Receive Data + • Pin 2 = Receive Data - • Pin 3 = Transmit Data + • Pin 6 = Transmit Data - Model: MIL-170TRM Table 1: Link Sentry Features Losing Link on RX of Stop sending Link on TX of...
  • Page 5 • Receive sensitivity: -36 dBm Op era tin g C ondi t i ons Table 2: Recommended Operation Conditions Operating Temperature Humidity: Non-condensing Signal Output Load Supply Voltage Model: MIL-170TRM Figure 2.RJ-45 Pinouts Parameters Minimum +5° C 35 ohm 4.75 V Maximum +50°...
  • Page 6 L eg al D ecla ra t i on Regulat o r y A pprovals • FCC Class A • UL 1950 • CSA 22 No. 950 • EN60950 • – EN55022 Class B – EN50082-1 Canad ia n EM I No tice This Class A digital apparatus meets all the requirements of the Canadian Interference-Causing Equipment Regulations.
