  • Page 1 ADAM 2 ADAM 2 FRAME 110‑220 V, ADAM 2 FRAME 110‑220 V installed, ADAM 2 FRAME WITHOUT POWER SUPPLIES Technical Manual...

  • Page 3: Table Of Contents

    Safety Copyright and Disclaimer Notices Important safety instructions Introduction Mounting the central matrix components ADAM 2 Reference Drawing ADAM 2 circuit cards Front card access Card installation and removal Unused back card slots Master controller card DIP switches Power supply sled removal and installation...

  • Page 4: Safety

    | Safety ADAM 2 Safety Copyright and Disclaimer All rights reserved. The product information and design disclosed herein were originated by and are the property of Bosch Security Systems, LLC. Bosch reserves all patent, proprietary design, manufacturing, reproduction, use and sales rights thereto, and to any article disclosed therein, except to the extent rights are expressly granted to others.
  • Page 5 ADAM 2 Safety | en Warning! To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. This product is AC only. CE Compliant and UL Certified Warning! This is a CLASS A product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures.

  • Page 6: Important Safety Instructions

    | Safety ADAM 2 Important safety instructions Read these instructions. Keep these instructions. Heed all warnings. Follow all instructions. Do not use this apparatus near water. Clean only with a dry cloth. Do not block any ventilation openings. Install in accordance with the manufacturer's instructions.

  • Page 7: Introduction

    (100-240 VAC), and supports redundant controllers, allowing for automatic change-over in the event of failure. ADAM 2 is available with a wide variety of Interface cards in the industry, including the MADI-16, OMI, AIO-16A, and RVON + interfaces. It also has the wide variety of cabling options, including RJ11, RJ45, DB9, jack fields, and many others.

  • Page 8: Mounting The Central Matrix Components

    | Mounting the central matrix components ADAM 2 Mounting the central matrix components Bolt the frame into the front of the equipment rack. Make sure the ventilation holes on the front and back are unobstructed. The rack space behind the frame should be completely clear to allow for connections and card installation and removal (at least two feet).

  • Page 9: Adam 2 Reference Drawing

    ADAM 2 ADAM 2 Reference Drawing | en ADAM 2 Reference Drawing Bosch Security Systems, LLC 2020-11 | 01 | F.01U.388.223 Technical Manual...
  • Page 10 | ADAM 2 Reference Drawing ADAM 2 Power supply rail LED indicators Power supply sled Power supply sled power switch Thumb screw (x 3) Chassis Handle (x 2) Alarm Override switch Card slots AC power connector AC Fuse 10. ADAM 2 power switch 2020-11 | 01 | F.01U.388.223...

  • Page 11: Adam 2 Circuit Cards

    Swing the door down. Card installation and removal It is not necessary to turn off the power to the ADAM 2 frame before installing or removing cards in the frame. This permits continuous operation of the intercom system with no interruptions to unaffected ports in the event of a card failure.
  • Page 12 Orient the card so the side connector edge is toward the bottom. Insert the card edges into the upper and lower guides in the back of the ADAM 2 frame. Push the card in until the mounting plate is flush with the ADAM 2 frame.
  • Page 13 Notice! Orient the front card so that the indicator LED and reset switch are at the top front. Insert the card edges into the upper and lower card guides in the front of the ADAM 2 frame. Push the card straight into the slot until you feel an initial resistance.

  • Page 14: Unused Back Card Slots

    | ADAM 2 circuit cards ADAM 2 To remove the front card, do the following: Unscrew the top and bottom screws, if installed. Simultaneously press down on the lower ejector lever and press up on the upper ejector lever.

  • Page 15: Power Supply Sled Removal And Installation

    Pull the power supply sled from the frame. To install the power supply sled, do the following: Push the power supply sled firmly into the designated slot in the ADAM 2 frame. Tighten the captive thumb screws. Turn the power supply sled power switch on.

  • Page 16: Ac Power Connection

    Place the power supply power switch on the front of each power supply sled to the off position. Attach a power cable to each AC power connector on the back of the ADAM 2 frame. Notice! Connecting both AC inputs insures continued operation of the ADAM 2 frame in the event that one power supply fails.

  • Page 17: Adam Frame Power-Up

    To power on the ADAM 2 frame, do the following: Place the ADAM 2 power switches in the on position. Notice! The ADAM 2 power switch in the on position illuminates the power supply sled power switch LED. Place the alarm override switch in the on position.

  • Page 18: Circuit Card Reset And Fail Indication

    | Circuit card reset and fail indication ADAM 2 Circuit card reset and fail indication Each front card has a reset button located near the top of the card. Directly under the reset button is a red LED fail indicator. The LED indicator remains off during normal operation. If the LED fail indicator turns on, first attempt to resort normal operation by momentarily pressing the reset button.

  • Page 19: Alarm Operation

    ADAM 2 Alarm operation | en Alarm operation If there is a power supply sled fault during operation, the audible alarm sounds and one or more power rail LED indicator lights on the affected power sled turn off. To deactivate the alarm, do the following: Set the alarm override switch to the off position.

  • Page 20: Frame Mapping (Multi-Frame Systems Only)

    | Frame mapping (multi-frame systems only) ADAM 2 Frame mapping (multi-frame systems only) Frame Mapping is used to assign the position of each frame in a multi-frame system intercom system. The frame order determines the port range assigned. For example, when mapping a 2- frame system, with each frame having 128 ports, the first frame is given ports 1 through 128.

  • Page 21: Intercom Port Connections

    For example, key press information transmits on the data wires to the ADAM 2 frame. The AIO card talks to the Master Controller, the ADAM 2 frame then makes the necessary talk and listen connections so that a conversation can take place. It also sends data to the receiving device, for example, to display the caller’s name at a keypanel, or to activate a...
  • Page 22 | Intercom port connections ADAM 2 In the Type column, delete as many card types as necessary to fit the required frame population. Deleting the card type also deletes the quantity of allocated ports and the port numbers. In the Type column, enter the correct card types.
  • Page 23 ADAM 2 Intercom port connections | en Using the Intercom Configuration Wizard, resize the frame to its actual frame size. Click the Test button. The mapping is tested. Notice! A popup window appears if mapping fails. Check the column entries and correct, as necessary.

  • Page 24: Kp Series Keypanels

    Plug the 24 VDC power connector of the power supply into the power connector on the back panel of the unit. Connect an RJ-12 or RJ-45 (568B or USOC) cable with RTS cabling to the J8 FRAME connector. Connect a CAT-5e cable to either J11 or J12 ETHERNET connector.

  • Page 25: Program Source Notes

    ADAM 2 Program source notes | en Program source notes – External audio program sources can be connected to intercom inputs, but all sources must be DC isolated. – The audio output and data pins for the port are not used.

  • Page 26: Tif Installation Notes

    | TIF installation notes ADAM 2 TIF installation notes Rear Panel DIP Switch (S201) The rear panel DIP switch contains switches to configure the most often changes options. These include: – Auto-answer on/off – Ring signal on/off – Password on/off –...

  • Page 27: Device Connections

    ADAM 2 Device connections | en Device connections Connections to ADAM 2 frame ADAM 2 has a variety of configurations to meet different user requirements. 16.1 Common cable assemblies ADAM INTERCOM SYSTEM AUDIO INPUT / OUTPUT / DATA 50 PINS SCSI-2 CABLE...
  • Page 28 | Device connections ADAM 2 ADAM INTERCOM SYSTEM MASTER CONTROLLER 68 PINS SCSI-2 CABLE TYPICAL 34 PAIRS 50 PINS 50 PINS SCSI-2 CABLE MALE SCSI-2 CONNECTOR MALE SCSI-2 CONNECTOR ASSEMBLY DETAILS SCSI-2 68 PINS MALE CONNECTOR NOMINAL LENGTH : 8 FT.
  • Page 29 ADAM 2 Device connections | en ADAM 2 INTERCOM SYSTEM AZEDIT TO PC RS-232-C CABLE DE-9-P DE-9-S MALE, 9 PINS FEMALE, 9 PINS " D " SUB " D " SUB CONNECT TO MATRIX CONNECT TO P. C. GROUND GROUND...
  • Page 30 | Device connections ADAM 2 COMMONING CABLE FOR CONNECTION OF GPIO-16 AND PAP TO XCP-ADAM-MC MASTER CONTROLLER BREAKOUT PANEL DE-9-P MALE, 9 PINS " D " SUB TO XCP-ADAM-MC J3 RS485 + DE-9-P MALE, 9 PINS RS485 - " D " SUB...
  • Page 31 ADAM 2 Device connections | en Figure 16.5: Intercom Station Cables Bosch Security Systems, LLC 2020-11 | 01 | F.01U.388.223 Technical Manual...

  • Page 32: Configuration Computer Connection And Check

    | Configuration computer connection and check ADAM 2 Configuration computer connection and check Us an RS-232 cable to connect from J1 of the XCP-ADAM-MC Breakout Panel to a COM port of the configuration PC. For cable wiring details, please refer to Device connections, page 27 .

  • Page 33: Pap-5032 Program Assign Panel

    PAP-5032 program assign panel | en PAP-5032 program assign panel The PAP-5032 connects to J3 on the ADAM 2 system. The baud rate, as well as all UIO-256/ GPIO-16, and LCP-102 devices have a fixed 76.8 k baud. For more information on the PAP-5032, see the PAP-5032 Technical Manual at www.rtsintercoms.com.

  • Page 34: Key Assignment From The Front Panel

    | PAP-5032 program assign panel ADAM 2 18.3 Key assignment from the front panel Notice! The PAP-5032 must be connected to the Intercom system to assign keys from the front panel. To assign a key from the front panel, do the following: Press the MENU key.

  • Page 35: Uio-256/Gpio-16

    The maximum number of devices that can be connected when using a GPIO-16 are as follows: Zeus, Zeus II, and ADAM CS - Four devices (64 relays) ADAM 2, ODIN and Cronus - 16 devices (256 relays) DIP Switch Settings...

  • Page 36: Connecting A Single Uio-256/Gpio-16

    | UIO-256/GPIO-16 ADAM 2 Relay Output Numbers PIN Numbers DC Control Input - DC Control Input+ (50-30 VDC) 1/17/33/49 2/18/34/50 3/19/35/51 4/20/36/52 5/21/37/53 6/22/38/54 7/23/39/55 8/24/40/56 9/25/41/57 10/26/42/58 11/27/43/59 12/28/44/60 13/29/45/61 14/30/46/62 15/31/47/63 16/32/48/64 Tab. 19.4: UIO-256/GPIO-16 opto-isolated inputs connector (J7) Dependent on UIO-256/GPIO-16 DIP Switch SW1 Settings for Input/Output Range.

  • Page 37: Connecting Additional Uio-256/Gpio-16

    ADAM 2 UIO-256/GPIO-16 | en 19.2 Connecting Additional UIO-256/GPIO-16 Up to 15 addition UIO-256-GPIO-16 frames may be connected in parallel bus configuration using the 15-pin ribbon cables provided. Connect the J3 output of the ADAM MC to the UIO-256/GPIO-16 via J2 on the UIO-256/ GPIO-16.

  • Page 38: Dsi-2008

    | DSI-2008 ADAM 2 DSI-2008 The DSI-2008 Dual Digital Hybrid interfaces two 2-wire intercom lines to two 4-wire intercom lines. Unlike earlier analog hybrids, the DSI-2008 features advanced digital signal processing to achieve automatic nulling of the 4-wire lines. In addition, each hybrid features convenient peak-reading level meters to quickly match the levels between the lines being interfaced.

  • Page 39: 4-Wire Call Signal Connections

    ADAM 2 DSI-2008 | en 20.3 4-wire call signal connections Notice! These connections require the call signal option. Part number 9002705500 Call signal connections Use the GPI (General Purpose Interface) connector to interface the call signals. The pin-out of the connector is the same for the following:...

  • Page 40: Ssa-324

    | SSA-324 ADAM 2 SSA-324 General Description The SSA-324 is a System-to-System Adapter (or interface). It interconnects the voice signals between different types of intercom systems. In addition, it can optionally interconnect intercom systems. In addition, it can optionally interconnect Calls or tally signals between systems.
  • Page 41 ADAM 2 SSA-324 | en J104 Power Input Earth 16VAC 16VAC J103 I/O Earth 4-wire Audio In Hi, System A 4-wire Audio In Lo, System A 4-wire Audio Out Hi, System A 4-wire Audio Out Lo, System A 4-wire Audio In Hi, System B...

  • Page 42: Operation

    Controls – Monitor headphone level (VOLUME) Indicator – Indicator (Power) green LED Controls – LEVEL TO RTS, System A – LEVEL FROM RTS, System A – DUCK Level, System A – Inductive (LOW) null, System A – Resistive (MEDium) null, System A –...
  • Page 43 – Have Talkers 1 and 2 on 4-wire system, Talkers 3 and 4 on 2-wire system. Adjust To/From RTS Controls so that all Talkers can hear each other at about the same level regardless of which system they are on.

  • Page 44: Power Supply

    To measure the power supply outputs, do the following: Turn on the power supply that needs adjustment. Open the ADAM 2 front door. Measure the voltage using a multi-meter with a standard banana plug between the GND test point and the test point corresponding to each power supply DC voltage rail.
  • Page 45 ADAM 2 Power Supply | en Using a flathead screwdriver, turn the voltage pot clockwise to increase the voltage. Turn the voltage pot counterclockwise to decrease the voltage. The voltage is adjusted accordingly. Notice! There are four adjustment pots on the power supply sled. The wiring and wiring harnesses are hidden from the voltage adjustment line drawing for pot placement clarity.

  • Page 46: Fuse Replacement

    | Power Supply ADAM 2 22.2 Fuse Replacement Figure 22.4: Fuse Location Location of 3, 8, and 12A fuses Location of each 25A fuse Caution! Use only approved replacement fuses: 3A - Littelfuse 0312003.HXP 8A - Littelfuse 0312008.HXP 12A - Littelfuse 0312012.HXP 25A - Littelfuse 0287025.PXCN or Eaton BK/ATC-25...
  • Page 47 ADAM 2 Power Supply | en Notice! If the ADAM 2 does not power up properly, verify the fuses are working. If needed, contact Bosch Security Systems, LLC technical support to replace the fuse for proper functionality. Bosch Security Systems, LLC 2020-11 | 01 | F.01U.388.223...

  • Page 48: Technical Data

    Caution! The ADAM2 is to be connected to a mains socket outlet with a protective earth. For more information on ADAM 2 frame accessory specifications, please refer to www.rtsintercoms.com. 2020-11 | 01 | F.01U.388.223...
  • Page 49 ADAM 2 Technical data | Bosch Security Systems, LLC 2020-11 | 01 | F.01U.388.223 Technical Manual...
