SIGNAL BOOSTER CEL-FI QUATRA 4000 Installation Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
CEL-FI
QUATRA 4000
I N S TA L L AT I O N G U I D E
PLEASE READ THIS FIRST
Thank you for purchasing the Cel-Fi Quatra 4000. It is the
most powerful signal booster in its class, but following the
instructions for set up is very important. This installation guide
contains everything we've learned from helping hundreds of
people just like you to boost their signal
Give this a read before you start, as it will save you time in the
long run.
Should you encounter any problems with your Cel-Fi Go X
installation, or would like someone to walk you through it, don't
hesitate to call us at 1-800-470-6777.
5010 Wright Road, Suite 110
Stafford, TX, 77477
1-800-470-6777
USA
www.signalboosters.com
sales@signalboosters.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CEL-FI QUATRA 4000 and is the answer not in the manual?

Questions and answers

Chris
April 18, 2025

why are two links plugged into a CU from a quatro 4000

0
1 comments:
Mr. Anderson
May 9, 2025

Two Ethernet links are plugged into a CU (Coverage Unit) for the CEL-FI QUATRA 4000 to connect it to the NU (Network Unit). These links provide both power (via PoE) and data, enabling the CU to receive signal from the NU and distribute it locally.

This answer is automatically generated

0

Related Manuals for SIGNAL BOOSTER CEL-FI QUATRA 4000

Summary of Contents for SIGNAL BOOSTER CEL-FI QUATRA 4000

  • Page 1 I N S TA L L AT I O N G U I D E PLEASE READ THIS FIRST Thank you for purchasing the Cel-Fi Quatra 4000. It is the most powerful signal booster in its class, but following the instructions for set up is very important.

  • Page 3: Table Of Contents

    CONTENTS 0 1. I NT R O D U CT I O N TO Q UAT R A 4 0 0 0 ............. 2 0 2. R E G U L ATO RY // M O D E L N U M B E R: C E L-F I Q UAT R A 4 0 0 0 ..... 4 0 3.
  • Page 4 There are a variety of Cel-Fi QUATRA product variants available, supporting a variety of band configurations, for multiple regions. This manual is applicable to the Cel-Fi QUATRA 4000 and 4000i ONLY, and does not apply to any other QUATRA variants.

  • Page 5: 1. I Nt R O D U Ct I O N To Q Uat R A 4 0 0 0

    I NT R O D U CT I O N TO Q UAT R A 4 0 0 0 Understanding Cellular Coverage Spotty cellular coverage, poor voice quality, dropped calls, and dead zones continue to plague occupants in buildings of all shapes and sizes. Cel-Fi QUATRA solves that problem.
  • Page 6 Q UAT R A 4 0 0 0 Comment About FCC Certification There are two variants available for the Cel-Fi QUATRA 4000: Cel-Fi QUATRA 4000 The QUATRA 4000 is FCC Part 20 certified ed. It supports bands 2, 4, 5, 12, 13...
  • Page 7 R E G U L ATO RY / M O D E L N U M B E R: C E L-F I Q UAT R A 4 0 0 0 The QUATRA 4000 is FCC Part 20 certified. Bands Supported Under This FCC Certification AT&T SPRINT T-MOBILE...

  • Page 8: R E G U L Ato Ry // M O D E L N U M B E R: C E L-F I Q Uat R A 4 0 0 0

    R E G U L ATO RY/M O D E L N U M B E R: C E L-F I Q UAT R A 4 0 0 0 I FCC Part 90 Certified. The QUATRA 4000i is FCC Part 90 certified. Bands Supported Under This FCC Certification AT&T SPRINT...

  • Page 9: S Ys T E Mov E Rv I E W

    OV E RV I E W How Does It Work? Cel-Fi QUATRA 4000 is a powerful cellular signal distribution solution. Cel-Fi QUATRA 4000 is fundamentally comprised of a Network Unit (NU) and up to six (6) Coverage Units (per NU). The Network Unit takes the donor input from up to four (4) carrier signal sources.
  • Page 10 Architecture Overview...
  • Page 11 Real World Examples 1. Off Air Install, 75K ft building In this example, Cel-Fi QUATRA is providing cellular coverage for four carriers in a six story 75,000 ft building. Individual LPDA antennas are located on the top of the building to ensure the best signal-to-noise ratio for all four carriers. Four coax cables are pulled through the roof to Network Unit.
  • Page 12 2. Supercell Install, 300K ft building This building did not have adequate donor signals for the four Operators, so small cells were chosen as the signal sources. The system is comprised of four (4) QUATRA 4000 systems served with one small cell from each wireless operator. The small cell signals are split and input to each QUATRA 4000 NU.
  • Page 13 3. Hybrid Install, Off-Air + Small Cell In this example, the building site has excellent (exterior) network service for two carriers, but the other two carriers’ outside signals are very poor. The System Integrator has decided to use a hybrid approach, taking off-air signals from the two carriers with good service and implementing small cells for the two remaining carriers.
  • Page 14 Cel-Fi QUATRA 4000 Key Features • Carrier Grade, FCC-certified Smart Signal Booster • Support for AT&T, Verizon, T-Mobile and Sprint • Relays two (2) bands per operator, simultaneously • Independent donor ports for each operator allows for independent antenna optimization •...

  • Page 15: H A R D Wa R E C O M P O N E Nt

    H A R D WA R E C O M P O N E NTS Cel-Fi QUATRA 4000 is a modular solution with two (2) foundational components: the Network Unit (NU) and the Coverage Unit (CU). In traditional DAS terminology these could be known as the Head End (NU) and the Remote Unit (CU).
  • Page 16 Network Unit (NU) The Network Unit, referred to as the NU, is the head end for the QUATRA 4000 system. The signal sources (one for each port/carrier) are connected to the NU. Then they are digitized and distributed over two Category“Ethernet” cables to the Coverage Units (CU).
  • Page 17 Power • AC Power Supply (inside the NU) • AC power cord Physical Interface • RJ45 ports (13) • Twelve RJ45 ports (2 for each of the 6 CUs) • One LAN port for remote management • SFP+ module dock (for use with a Fiber HUB) •...
  • Page 18 Coverage Unit (CU The Coverage Unit (CU) receives the digitized cellular signal from the NU, converts back to RF, amplifies, and distributes the service from its RF port. Service can be deployed through a single connected antenna, or through a DAS field. QUATRA 4000 Coverage Unit The Coverage Unit includes a multi-band blade style antenna that can be connected directly to the CU.
  • Page 19 Accessories QUATRA 4000 FIBER HUB Model Number: Q40-1234FNU The HUB functions much like an NU, except it does not have donor antenna ports. It connects to an NU over optical fiber cable (up to 2km) using SFP+ modules, and it adds up to six more CUs to an NU (twelve CUs total). QUATRA 4000 FIBER HUB...
  • Page 20 QUATRA 4000 Range Extender (QRE4K) Model Number: Q40-OE The QRE-4K unit is a device that extends the standard 100 meter cable length from NU to CU up to 200 meters with Cat5e, or up to 300m if CAT6/7, 23AWG cable is used.
  • Page 21 Donor Antennas The donor antennas are used to provide off-air signals to individual carrier donor input ports. The objective is to provide the best quality carrier signals to the NU. A variety of donor antennas are available from Nextivity. The right donor antenna choice can make the difference between a good outcome and a great outcome.
  • Page 22 Server Antenna The server antenna connects to the RF port on the CU. Server Antenna port A variety of Server antennas are available from Nextivity. Visit the Antenna Product page for details and updates. Couplers RF couplers or tappers may be used with Coverage Units when multiple service antennas are desired.

  • Page 23: 6. T H E Wav E P O Rta

    The WAVE Portal Introduction Cel-Fi WAVE is Nextivity’s SOC2 Type 1 compliant cloud-based software platform from which Cel-Fi apps and connected capabilities are hosted and driven. Current-generation Cel-Fi products feature embedded connectivity that allows them to connect to the WAVE cloud. The WAVE portal and apps are used to facilitate software updates, registration, commissioning, installation, optimization, and troubleshooting.
  • Page 24 Alarms, Alerts, and Policies Cel-Fi systems support a variety of standard alarm conditions. Use the Notifications page in the WAVE portal to view a listing of notifications (alerts) sent to inform specific users of alarm conditions occurring in installed systems, or assets within systems. You can access and view Notification Detail by double-clicking a displayed notification.

  • Page 25: 7. I N S Ta L L At I O

    Installation Important: Before any permanent installation, make sure all the components are planned and accounted for, as well as any wiring, cabling, power, mounting, antenna placements, and system access. Overview Several things need to be determined as part of installation planning and preparation.
  • Page 26 The QUATRA 4000 NU has four (4) secure mounting tabs, two on each side. The two topmost tabs have been keyholed. Note: The Mounting Instructions below use the standard drywall mounting anchors and screws included with the unit. If the NU is to be mounted onto other surfaces, make sure the appropriate anchors and screws are used (not included).
  • Page 27 3. Drill the holes for the anchors. 4. Hammer in the anchors. 5. Partially screw in the top two screws.
  • Page 28 6. Hang the unit from the top two screws, through the eye holes. Adjust the unit to level and then tighten the screws 7. Screw in the bottom two screws. 8. Mounting is complete.
  • Page 29 Connecting Donor Sources The QUATRA 4000 has four independent RF ports for connecting the donor signal. Each port: • Is an N-type Female connector • Is specific to the supported operator • Is designed to support a variety of band configurations Donor Antenna Each RF port can be fed by a donor signal consisting of either a small cell or an antenna.
  • Page 30 Power The QUATRA 4000 system is powered from the Network Unit (NU). The NU comes with a power cord that plugs in to the back of the unit. The Coverage Units (CU) are Powered-over-Ethernet (PoE) and therefore do not have independent power supplies that need to be plugged in.
  • Page 31 Installing a CU Wall Mounting The Coverage Unit (CU) comes with a wall mounting bracket in the box. To mount the QUATRA 4000 CU simply follow these steps: 1. Determine mounting location. Note: Whenever mounting any Cel-Fi gear on a wall or ceiling make sure the area is free of any dangerous electrical wires, other safety hazards, or any other objects that could be damaged or effect the quality or stability of the mounted unit.
  • Page 32 4. Drill the holes. 5. Hammer in the anchors. 6. Attach the bracket to the wall with the included screws.
  • Page 33 7. Once the bracket is firmly attached to the wall, the CU can be attached to the bracket. 8. With the bracket in place, attach the CU. 9. Tighten (finger) each Locking Screw into place to ensure the CU is securely attached.
  • Page 34 Connecting Server Antenna(s) The CU has an N-type connector on the top of the unit for attaching an antenna. An Omni-directional antenna is included with each CU, or a coaxial cable can be connected with a series of passive antennas attached. Server Antenna port Connecting NU and CU Each CU connects to the NU using two Ethernet cables (Cat5e or better).

  • Page 35: L E D

    Using a QRE If cable distances greater than 100 meters from NU to CU are required (150m if using 22/23 AWG CAT6/7 cable),a QUATRA RANGE EXTENDER (QRE-4K) may be used in the middle of the cable run to achieve lengths up to300m. Note: Only the QUATRA 4000 RANGE EXTENDER (QRE-4K) may be used.
  • Page 36 The LEDs on the front of the QUATRA 4000 function as follows: LED LABEL LED STATE MEANING POWER NO LIGHT No power SOLID GREEN Powered and operating normally FLASHING GREEN Scanning to acquire network signals SOLID RED Hardware error FLASHING RED Error CU1, CU2, CU3, NO LIGHT...
  • Page 37 Each QUATRA 4000 CU has three (3) LEDs on the front of the unit, used as status indicators, during setup and normal operation. The LEDs are labeled. CU LEDs The meaning for each LED on the CU is shown in the table below. LED LABEL LED STATE MEANING...

  • Page 38: D I Ag N O S T I C S A N D T E S T I N

    Diagnostics and Testing WAVE PRO and COMPASS Introduction Cel-Fi COMPASS is a hand-held battery operated device specifically designed to simplify the installation of all QUATRA variants, without the need for an Internet connection to the WAVE Portal in the cloud. Note: The WAVE Portal is a very powerful and time saving system.
  • Page 39 Cel-Fi QUATRA Installation Features Overview When it’s not possible to open a LAN connection between a Cel-Fi QUATRA Network Unit (the NU) and the Cel-Fi WAVE Portal, these features will help installers setup Cel-Fi systems quickly and efficiently. While complete provisioning and optimization using the WAVE Portal is preferred, we understand that it’s not always possible.
  • Page 40 CU port assignment on the NU Band Settings 1. All Cel-Fi QUATRA variants will select bands and channels to relay automatically. 2. Optionally, bands may be enabled/disabled using the Bands Settings feature using COMPASS and the WAVE Pro app. • From the main menu, tap on “Bands Settings” •...
  • Page 41 Cel-Fi QUATRA Optimization Features Antenna Positioning The QUATRA 4000 system can accept up to four individual donor signals. One per carrier. Each donor can be established to the system either via small cell or off-air. When using an off-air signal, a directional antenna is recommended to provide the best signal quality.
  • Page 42 Steps 1. Make sure the Cel-Fi COMPASS is connected to the donor antenna using the (included) RP-SMA to N adapter cable. 2. The SIM card in COMPASS must be removed when using this feature. 3. Click on “Antenna Positioning” in the WAVE PRO app. 4.
  • Page 43 Signal Report A Full Signal Report scans all bands and channels for each carrier and returns a list of the channels it finds with RF metrics. 1. The SIM card in COMPASS must be removed when using this feature. 2. Go to the optimization section in the WAVE PRO app and click on “Full Signal Report”.
  • Page 44 Speed Test This feature tests the speed of the current Network Carrier of the SIM card inserted into the COMPASS. 1. In the WAVE PRO app, go to the “Optimization” section and press the “Speed Test” button. 2. Click on “Start,” and The Cel-Fi COMPASS will gather data for several minutes and display the results below.
  • Page 45 Serving Cell Report The Serving Cell Report is a live reading of the current Network Carrier of the SIM card inserted into the Cel-Fi COMPASS. The data will constantly refresh while on the page.

  • Page 46: A Dva N C E D I N F O R M At I O N - A Nt E N N A S A N D Q Uat R

    Signals spread over the full bandwidth and narrow band. A minimum of -20 dB SINR (of the S-Synch channel) is needed to detect RSRP/RSRQ. In the context of Cel-Fi QUATRA 4000, the following stratification of quality is recognized: 2. SINR. Signal to Noise Ratio. The SINR is the ratio of the usable (desired) signal over the noise.
  • Page 47 3. How strong is the serving signal? Although Cel-Fi QUATRA 4000 has the highest gain of any antenna in its class, if the serving signal is extremely weak, then a high-gain antenna may be required to connect the uplink calls and to get the optimal DL power on the serving side.
  • Page 48 MIMO. (Cel-Fi QUATRA 1000 supports MIMO.) A SISO (single in, single out) antenna has a single coaxial (pigtail) cable feed and/or connector, and works best with SISO systems. Cel-Fi QUATRA 4000 is a SISO system.
  • Page 49 A variety of mounting methods can be employed through the integration of off-the-shelf accessories. Note: The Cel-Fi QUATRA 4000 Coverage Unit is plenum rated. Specifications For details, please refer to the Cel-Fi QUATRA 4000 Data Sheet...
  • Page 50 Trademarks Cel-Fi, IntelliBoost, and Nextivity logo are trademarks of Nextivity, Inc. Warranty & Limitation of Liability Nextivity Inc., provides a limited warranty for its products. 8/19/22, 11:34 AM QUATRA 4000 Installation and User Guide – Cel-Fi Support https://support.cel-fi .com/hc/en-us/articles/360039366174-Cel-Fi-QUATRA-4000- Installation-and-User-Guide 38/41 For details, please refer to cel-fi .com/warranty.

  • Page 51: G Lo S S A

    Antenna used to capture the exterior macro cellular network signal, and provide such signal to the system. Server Antenna Antenna used internally to provide the coverage benefit from Cel-Fi QUATRA 4000. Troubleshooting Alarm Error Description Network Unit Hardware Error Power cycle the Network Unit (NU) and check for software updates.
  • Page 52 Glossary Term Definition Coverage Unit Hardware Error Troubleshoot any Network Unit (NU) error first, and check for software updates. Make sure Coverage Unit (CU) cables do not exceed recommended cable length maximums. Note that standard Ethernet Extenders or active LAN switches and routers will not work with CU cabling.
  • Page 53 Disabled by Operator/Vendor Your system has been disabled by the mobile network operator or vendor. Contact your vendor for further assistance. Location Lock Your system has been moved from its original address. Please move the system back to its original location or register your new address with your wireless provider.
  • Page 54 NEED HELP? WE’RE READY AND WAITING. Signal boosters aren’t always easy to install. In fact, getting everything up and running can sometimes be a pain. But the end result is worth it. SignalBoosters.com provides lifetime technical support on every system we sell. We’ve installed hundreds of these devices ourselves, and can walk you through troubleshooting and fine-tuning your installation for best results.
