SIGNAL BOOSTER Pro 1000 Quick Start Manual

Pro 1000
SKU: 460236 AVAILABLE NOW
FEATURES
• Industry-best +15 dBm maximum downlink power
• XDR technology: never shuts down, even with very
strong outside cellular signals
• Full color display, indicating gain and power levels of
each band, for easy antenna setup
• Compatible with all North America cell networks
• Integrated power supply
Kit Includes
1000R Booster
Directional Antenna
About
The WilsonPro 1000 passive distributed antenna system is
a cellular amplifier designed to provide enhanced in-building
cellular coverage for all commercial spaces, including
hospitals, hotels, warehouses and offices.
The WilsonPro 1000 amplifies weak cellular signals to pro-
vide reliable voice and data coverage–including 4G – to
inside spaces where signals may not penetrate and With new
eXtended Dynamic Range (XDR) technology, the amplifier
never shuts off due to a strong outside signal or changes in
outside signals.
Like all WilsonPro cellular amplifiers, the WilsonPro 1000
features cell site protections that auto-detect and prevent
any cell tower interference.
Outside Inside Dome
Antenna
(314411) (304412)
RACK MOUNT OPTION:
Lightning Surge 2ft Low-Loss
Protector Wilson400 Cable
(859902) (952302)
Specifications
MODEL NUMBER
FREQUENCIES
MAX GAIN
IMPEDANCE
POWER
CONNECTORS
DIMENSIONS
WEIGHT
Pro 1000R
AVAILABLE NOW
SKU: 460237
75ft Low-Loss 100ft Low-Loss
Wilson400 Cable Wilson400 Cable
(952375) (952300)
460237 • 460236
Band 12 700 MHz
Band 13 700 MHz
Band 5 850 MHz
Band 4 1700/2100 MHz
Band 25/2 1900 MHz
70 dB
50 Ohm
110 - 240 V AC, 50 - 60 Hz, 30 W
N-Female
3.75 x 11.5 x 18 in • 1.75 x 19 x 12.5 in
15.405 lbs • 5.45 lbs
