Summary of Contents for Hultafors HXL
- Page 1 QUICK START 1 On/off switch, transport lock 2 Status-/Battery voltage display “BATT-ON” 3 Operating modes button “MODE” 4 Operating mode status “PULSE” 5 Tripod adapter 1/4" 6 Stand with rotatable foot...
- Page 2 QUICK START Switching on/off Turn the on/off switch to the left (ON position) and the pendulum unit will be released. The instrument will level itself automatically within the specified inclination range. OFF: Turn the on/off switch to the right (OFF position) and the pendulum unit will be locked.
- Page 3 Horizontal leveling Vertical leveling...
- Page 4 Cross leveling Working at distance In PULSE mode use a receiver (part no. 409091)
- Page 5 90° angle Quick battery replacement...
- Page 6 IP54 Please find the operating instructions on hultafors.com Hultafors Hultaforsvägen 21 | Hultafors | Sverige Phone +46 (0)33 723 75 50 | info@hultaforsgroup.se hultafors.com 317844 091204 Art.no. 409120...
