- Page 1 DAS35XL Cordless screwdriver with Battery charger USER'S MANUAL www.daewoopowerproducts.com Manufactured under license of Daewoo International Corporation, Korea...
-
Page 2: Table Of Contents
ÍNDICE 1. GENERAL SAFETY INSTRUCTIONS ..................... 4 2. MACHINE DESCRIPTION AND INCLUDED CONTENTS ..............7 3. ASSEMBLY OF THE MACHINE ......................7 4. PUTTING INTO OPERATION ........................8 5. INSTRUCTIONS FOR PROPER USE ..................... 8 6. OPERATING INSTRUCTIONS ........................ 8 7. - Page 3 Pic 1...
- Page 4 Pic 2 Pic 3 Pic 4 Pic 5...
-
Page 5: General Safety Instructions
1. GENERAL SAFETY INSTRUCTIONS WARNING! Carefully read the instruction manual before use. Important safety warnings • Unpack the product carefully and be sure not to throw away any part of the package before having found all components of the product. •... - Page 6 Do not use any adapter plugs with earthed (grounded) power tools. Undamaged plugs and matching outlets will reduce risk of electric shock. Damaged or fouled supply cables increase the risk of electric shock. If the power cord is damaged, it must be replaced by a new power cord which is available at the authorised service centre or the importer.
- Page 7 • Never use power tools if you are under the influence of alcohol, drugs, medication or other narcotic or addictive substances. • This equipment is not intended for use by persons (including children) with limited physical, sen- sual or mental capacities or lack of experience or knowledge unless they are supervised or instruc- ted about the use of the equipment by a person responsible for their safety.
-
Page 8: Machine Description And Included Contents
Service • Do not replace parts of the power tool, do not make any repairs or interfere in any way with the construction of the power tool. Have your power tool repaired by qualified repair persons. • Any repair or modification of the product without our company’s authorisation is impermissible (it could cause injury or damage to the user). -
Page 9: Putting Into Operation
handle pivot (Pic 1, no. 2) and turn the handle back anticlockwise again until it clicks into the pistol position of the screwdriver. 4. PUTTING INTO OPERATION Charging the machine (See Pic. 11) If you wish to charge the battery, connect the adapter to a power socket (230 V ~ 50 Hz) and insert the charger connector into the jack in the handle of the machine (Pic 1, no. - Page 10 • Never allow children or persons who do not know the contents of this user's manual to work with the device. Local regulations may set the mínimum age of the user. The user is responsible for damages caused to third porties in the machine's working orea as a result of its use. •...
-
Page 11: Maintenance And Storage
• The plug must be powered at 230 V - 50 Hz. • Disconnect the charger if you will not be using it for a long time, if you are changing the tool or performing maintenance on the tool. 7. MAINTENANCE AND STORAGE Maintenance ATTENTION: Disconnect the charger if you will not be using it for a long time, if you are chan- ging the tool or performing maintenance on the tool. -
Page 12: Technical Specifications
8. TECHNICAL SPECIFICATIONS MODEL DAS35XL 3.6 V Li-ion / 1300 mAh Battery 210 rpm Speed Level of acoustic pressure 72 dB (A) Chuck 1/4" (ø 6.35 mm) CHARGER DABC-35 Battery charger data 220 V / 50 Hz 3 - 5 hour... -
Page 13: Warranty
WARRANTY CARD Product model Date of sale Company Serial number Client's signature Username The product is in good conditions and fully complete. Read and agree the terms of the warranty. GUARANTEE The warranty period starts from the date of sale of the products and covers 1 year for all power products. During the warranty period, free failures caused due to the use of poor-quality materials in the production and manufacturer workmanship admitted fault are removed. - Page 14 Manufactured under license of Daewoo International Corporation, Korea...
