Memorex MVT2135B Owner's Manual

Combination 13" color television and video cassette recorder
Hide thumbs Also See for MVT2135B:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Service Manual, Owner's Manual
OWNER'S MANUAL
MANUAL DE INSTRUCCIONES
COMBINATION 13" COLOR TELEVISION AND
VIDEO CASSETTE RECORDER
COMBINACION DE 13" TELEVISOR A COLOR Y
VIDEO GRABADOR
MVT2135B
If you purchase a universal remote control from your local retailer, please
contact the remote manufacturer for the required programming code.
Si usted a comprado un control remoto universal, por favor comunicace con
el fabricante para el codico de programaccion requerido.
When shipped from the factory, the TV/CATV menu option is set to the "CATV"
(Cable Television) mode.
If not using CATV, set this menu option to the "TV" position.
Al salir la unidad de fábrica, la opción de menú de TV/CATV se ajusta al modo
de "CATV" (Televisión por cable).
Si no utiliza CATV, ajuste esta opción de menú al modo de "TV".
Before operating the unit, please read this manual thoroughly.
Antes de usar la unidad, lea detenidadmente este manual de instrucciones.
5A30401A E COV.
ATTENTION
ATENCION
TV/CATV MODE SELECTION
SELECCION DE MODO DE TV/CATV
1
8/20/01, 12:53 PM

Advertisement

Table of Contents
loading

Related Manuals for Memorex MVT2135B

Summary of Contents for Memorex MVT2135B

  • Page 1 (Cable Television) mode. If not using CATV, set this menu option to the "TV" position. Al salir la unidad de fábrica, la opción de menú de TV/CATV se ajusta al modo de "CATV" (Televisión por cable). Si no utiliza CATV, ajuste esta opción de menú al modo de "TV".

  • Page 2: Important Safeguards

    - Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. - Consult the dealer or an experienced radio/TV technician for help. CAUTION: Changes or modifications not expressly approved by the partly responsible for compliance with the FCC Rules could void the user's authority to operate this equipment.
  • Page 3 IMPORTANT SAFEGUARDS 9. VENTILATION Slots and openings in the cabinet back or bottom are provided for ventilation, and to ensure reliable operation of the unit, and to protect it from overheat- ing. These openings must not be blocked or covered. The openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface.
  • Page 4 IMPORTANT SAFEGUARDS 19. DAMAGE REQUIRING SERVICE Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following conditions: a. When the power-supply cord or plug is damaged. b. If liquid has been spilled, or objects have fallen into the unit.

  • Page 5: Precautions

    PRECAUTIONS MOISTURE CONDENSATION DO NOT OPERATE ANY FUNCTIONS ON THIS UNIT FOR AT LEAST TWO OR THREE HOURS WHEN MOISTURE IN THE AIR CONDENSES ON IT. LET THE UNIT STAND WITH POWER ON (SEE BELOW). I WHAT IS MOISTURE CONDENSATION? When a cold liquid is poured into a glass, for example, water vapor in the air will condense on the surface of the glass.

  • Page 6: Features

    Programmable ON/OFF Timer - Allows you to automatically turn on or off the TV/VCR at a set time. Programmable TV Sleep Timer - Operable from the remote control, the TV can be programmed up to 120 minutes to turn off automatically. 8/20/01, 12:53 PM...

  • Page 7: Table Of Contents

    TV channel selected on the TV/VCR can be viewed. V-Chip - The V-Chip function can read the rating of a TV program or movie content if the program is encoded with this information. V-chip will allow you to set a restriction level.

  • Page 8: Location Of Controls

    1. Cassette Loading Slot - To insert or remove a video tape. 2. POWER Button - Press to turn the TV/VCR on or off. 3. STOP/EJECT Button - Press once to stop the tape in any mode. Press again to eject the tape.

  • Page 9: Remote Control

    24. PAUSE/STILL Button - During recording, this button temporarily stops the tape. During playback, it stops the tape and displays a still image on the TV screen. 25. STOP Button - Press once to stop the tape.

  • Page 10: Antenna Connections

    If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a cable TV service (CATV), see page 11 for Cable TV connections. Combination VHF/UHF Antenna ( Single 75 ohm cable or 300 ohm twin-lead wire ) Connect the 75 ohm cable from the combination VHF/UHF antenna to the Antenna Jack.

  • Page 11: Cable Tv Connections

    FOR SUBSCRIBERS TO SCRAMBLED CABLE TV SERVICE If you subscribe to a cable TV service which requires the use of a Converter/Descrambler box, connect the incoming 75 ohm Coaxial Cable to the Converter/Descrambler box. Using another 75 ohm Coaxial Cable, connect the output jack of the Converter/Descrambler box to the Antenna Jack on the TV/VCR.

  • Page 12: Auto Clock Setting

    (Month, Day, Year and Time) when the TV/VCR is connected to an Antenna or Cable system and it is turned off. As the TV/VCR searches for a receivable station in your area, it will also receive a broadcast signal for Auto Clock which will automati- cally set the clock and date.The Auto Clock needs sev-...

  • Page 13: Manual Clock Setting

    To move cursor backward, press the CANCEL button. 5A30401A E P12-19 TV OPERATION To turn on the TV/VCR, press the POWER button. Adjust the volume level by pressing the VOLUME Up or Down button. The volume level will be indicated on the screen by green bars.

  • Page 14: Quick View

    PHONES jack on the front. The sound from the TV speaker is muted. SLEEP To set the TV/VCR to turn off after a preset amount of time, press the SLEEP button on the remote control. The clock will count down 10 minutes for each press of the SLEEP button (120, 110, ...10, 0).

  • Page 15: To Memorize Channels

    • Some cable systems and copy protection systems may interfere with the Closed Captioned signal. • If using an indoor antenna or if TV reception is very poor, the Closed Caption Decoder may not appear or may appear with strange characters or misspelled words.

  • Page 16: Setting The V-Chip

    - Keep pressing VOLUME M button and press "0" key of remote control simultaneously for a few seconds. • If you are changing channels using a cable box, while the TV/ VCR remains on channel 3 or 4, the V-Chip operates differently.

  • Page 17: To Set The On Timer

    “ON” timer once, the TV/VCR will turn : PG–13 “on” on the programmed day (daily/weekly) at the same time to the same channel. EXAMPLE: Turning on the TV to channel 12 at 7:00 AM, MONDAY-FRIDAY. : ON Press the MENU button.

  • Page 18: To Set The Off Timer

    TO SET THE OFF TIMER This feature allows you to have the TV/VCR turn “OFF” automatically at a predetermined time. If you program the OFF TIMER once, the TV/VCR will automatically turn off at the same time everyday. EXAMPLE: Turning off the TV at 11:30 PM.

  • Page 19: Playback

    “AUTO TR.” will appear for 4 seconds on the screen. TO MONITOR A TV PROGRAM Press the TV MONI. button while in the playback mode.The video tape will continue to play while the picture switches to the TV channel selected on the TV/VCR. Press the button to return to the playback picture.

  • Page 20: Special Playback

    • The audio output is muted during Speed Search and Still. • A few noise bars will appear on the TV screen during Speed Search and Still. • To prevent damage to the tape, Still and Speed Search mode is automatically changed to the Playback mode after 5 minutes.

  • Page 21: One-Touch Timer Recording (Otr)

    Timer Recording is not possible. If a tape without an erase prevention tab is in the TV/VCR, the tape will be ejected. • To record from the external equipment press the SET/TRACKING + or – button repeatedly until "L"...

  • Page 22: Using The Real Time Tape Counter

    WKL-THU (Weekly Thursday) (Weekly Wednesday) TO CONFIRM THE SETTINGS Press the PROGRAM button once. The TV screen displays the timer program list. Press the PROGRAM button again. The TV screen displays the ON/OFF timer setting. (once) (twice) 23 TH 7:00...

  • Page 23: Duplicating A Video Tape

    Press the PAUSE/STILL buttons on both units simultaneously to begin the duplicating process. NOTES: • It is recommended that the tape speed be set to the SP mode on the TV/VCR for best result. • Unauthorized recording of copyrighted television programs, films, video cassettes...

  • Page 24: Troubleshooting Guide

    Picture wobbles or drifts. connected or possible local interference. Cable TV channel is scrambled. CATV connector is not connected. TV/CATV Mode menu option is set to No CATV reception. the TV mode. Cable TV service interrupted. TV/CATV Mode menu option is not No reception above set to the appropriate mode.
  • Page 25 WWW.MEMCORPINC.COM OR CONTACT CUSTOMER SERVICE AT 1-800-919-3647 PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX. FOR PARTS AND ACCESSORIES, CONTACT FOX INT'L AT 1-800-321-6993."...

  • Page 26: Reception Disturbances

    The most common types of television interference are shown below. If one of these symptoms appear when the TV/VCR is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

  • Page 27: Specifications

    SPECIFICATIONS TELEVISION Picture Tube: 13" (measured diagonally) Horizontal Resolution: 260 lines Tuner Type: Quartz PLL Frequency Synthesized Receiving Channels: CATV Antenna Input: VHF/UHF In 75 ohms coaxial Speaker: 1-1/2" x 2-1/2", 8 ohm x 1 Audio Output Power: 1.5W Video System: VHS, 2 Rotary Heads Helical Scanning System.
  • Page 28 MEMO 5A30401A E P20-Back 8/20/01, 12:54 PM...
  • Page 29 MEMO 5A30401A E P20-Back 8/20/01, 12:54 PM...
  • Page 30 Memcorp,Inc. Weston,FL 33331 Printed in Thailand Impreso en Tailandia Visit our website at www.memcorpinc.com 5A30401A Visite nuestro portal de internet en www.memcorpinc.com 01/10 5A30401A S P20-Back 8/20/01, 2:42 PM...
