BRAND-MAN Rustler 2 BG2211A6 Owner's Manual

6 burner

Advertisement

Quick Links

WARNING
FOR YOUR SAFETY:
For Outdoor Use Only
(Outside any enclosure)
WARNING
FOR YOUR SAFETY:
• Improper Installation,
adjustment, alteration,
service or maintenance can
cause injury or property
damage.
• Read the installation,
operation, and maintenance
instructions thoroughly
before installing or
servicing this equipment.
• Failure to follow these
instruction could result
could cause property
damage, personal injury, or
death.
• This instruction manual
contains important
information necessry for
the proper assembly and
safe use of the appliance.
• Read and follow all
warnings and instructions
before assembling and
using the appliance.
• Follow all warnings and
instructions when using the
appliance.
• Keep this manual for future
reference.
WARNING
• Do NOT store or use
liquids or vapors in the
vicinity of this or any other
appliance.
• An LP cylinder not
connected for use shall
NOT be stored in the
vicinity of this or any
other appliance.
Rustler2 - 6Burner
Model# BG2211A6
Keep this manual for future reference.
This instruction manual contains important information necessary for the
proper assembly and safe use of the appliance.
Read and follow all warnings and instructions before assembling and using
the appliace.
Follow all warnings and instruction when using the appliance
DANGER
If you smell gas -
• Open lid.
• If odor continues, keep away from the appliance and
MD
