OWNER'S MANUAL

CONVERSION INSTRUCTION FROM

PROPANE TO NATURAL GAS

TEL: 1300 667 146

WARNING

with the manufa cturer' s instructions and all appli cable codes and requirements

of the authori ty having jurisdiction. If the information in these inst ructions is not

agency is responsible for the proper and complete until the operation of the con-

plied with the kit."

Conversion kit suitable for BG2211A3/BG2211B3/

BG2211A4 /BG2211A6

Tools are NOT included.

Need help?

Do you have a question about the BG2211A3 and is the answer not in the manual?

Questions and answers

Summary of Contents for BRAND-MAN BG2211A3

Page 1 If the information in these inst ructions is not agency is responsible for the proper and complete until the operation of the con- plied with the kit.” Conversion kit suitable for BG2211A3/BG2211B3/ BG2211A4 /BG2211A6 Tools are NOT included.
Page 2 WARNING! PRECAUTIONARY LEAK TEST LEAK TESTS MUST BE CARRIED OUT IN A WELL VENTILATED AREA • ‘OFF’ position. • Open the gas control valve on the gas cylinder or regulator. • To check for gas leaks a solution of soapy water is required NEVER USE AN OPEN FLAME TO CARRY OUT A GAS LEAK TEST •...
Page 3 ASSEMBLY INSTRUCTIONS ASSEMBLY INSTRUCTIONS (CONTINUE) Step 1 1) Open the BBQ hood. 3) Put it aside. Figure Figure 2 Figure 3 Step 2 1) Remove the R-pin at the end of the burner as in Figure 4. 2) Remove all the burners carefully and put it aside as in Figure 5. Figure 4 Figure 5...
Page 4 ASSEMBLY INSTRUCTIONS Step 3 1) Unscrew the Propane injectors out in the anti-clockwise direction. 2) Put the Propane injectors in a safe place. The injector is a 2 step unit. Remove the Propane injector and the NG injector is already there and ready for use. Note: when unscrew and screw on the injectors from or onto the valve carefully and dont overpressure.
Page 5 4) Put back in the side burner (Figure 4). 5) Secure back the side burner with the two screws removed in step 1 as in Figure 5. 6) Put back the trivet (Figure 6). Note: This step does not apply to BG2211A3. Figure 2 Figure 1...
Page 6 ASSEMBLY INSTRUCTIONS 1) Remove the Propane hose & regulator from the manifold as shown below. Step 7 2) Connect the Natural Gas hose onto the connector at the end of the manifold as show below. 3) Connect to the Natural Gas supply connector at your property. Note: Ensure to run a leak test with soapy water after the NG hose changeover.
Page 7 ASSEMBLY INSTRUCTIONS Step 9 1) Connecting the NG quick connect to the NG supply as shown below. Note: ensure the NG supply valve is in OFF position before connecting or disconnecting. Pull back collar on connector...
Page 8 OPERATING INSTRUCTION Operating Main Burners Figure 1 First Use moved from the Barbecue. 2. Light Barbecue per “Lighting” section. 3. Remove manufacturing oils before cooking on this Barbecue for the 4. Season your Barbecue cooking surface per “Seasoning Barbecue” Figure 2 section.
Page 9 OPERATING INSTRUCTION 1. Turn NG gas valve to “CLOSED”. 3. Turn all control knobs clockwise to the “OFF” position. Note: A “poof” sound is normal as the last of the NG gas is burned. Controlling Flare-ups CAUTION: in serious burns, bodily harm or other damage. Do NOT attempt to extinguish with water.
