Agri-Fab H.D. Lawn Roller 45-01792 Owner's Manual

Agri-Fab
OWNERS
MANUAL
MODEL NO.
45-01792

SAFETY PRECAUTIONS

1. Never attach a garden hose to the fi ll/drain hole when
fi lling. Dangerous pressure build up could occur inside
roller.
2. Do not fi ll roller to maximum weight without checking
capability of vehicle to safely pull and stop.
3. Never use roller up and down hills; always work across
hills and slopes.
4. Use caution when turning, slowing or stopping.
5. Always drain roller to keep from freezing.
Printed in USA
®
© 2004 Agri-Fab, Inc.
H.D. LAWN ROLLER
(24" Dia. x 36" Wide)

SPECIFICATIONS:

Roller Drum:
O.A. Width:
Bearings:
Tow Hitch:
Weight w/ Water: Up to 640 Lbs. Filled with Water
Approx. Sh. Wt.: Approximately 105 Lbs.
24" Dia. x 36" Wide, Welded Steel
Approximately 40"
1" I.D., Replaceable
Std. Pin Type - 1/2" Hole
(Note: May be fi lled with sand)
Form No. 49538 (10/04)
