mettatec X5 User Manual

GNSS X5 PPK Module
for DJI Phantom 4 Pro
Convert your Phantom 4 Pro v.1 /
v.2 / Advance into a PPK system.
Easy integration without the
need to open or modify your
Drone.
Description
The X5 PPK Module for Phantom 4 Pro is a-non intrusive GNSS adapter system to
connect to a DJI Phantom 4 Pro v.1/v.2 or Advance Drone (not included).
Main Advantages:
Contains its own high quality GNSS Receiver module with state-of-the-art components
No need to open or modify your Drone (keep your Drone's original warranty)
The X5 PPK Module attaches and disattaches in seconds
No Batteries required
Ultra-fast image triggering detector sensor
Lightweight microelectronics: 80 grams
Trigger Sensor:
A sensor installed externally on the P4P drone detects the triggering of each photograph
and records a time stamp in the log file of the MULTIBAND X5 GNSS module. Timestamps
are extracted from the module after flight and combined with the in-flight imagery as
centimeter-accurate position geotags (geotagging) using various specialized software
options available on the market. The new X5 GNSS Module is a centimeter-accurate
multiband GNSS system for UAV mapping.
