- Page 1 ATS Overhead Table Shelf System NSTRUCTION ANUAL...
- Page 2 ATS Overhead Table Shelf System Instruction Manual...
-
Page 3: Warranty
Warranty Newport Corporation warrants this product to be free of defects in material and workmanship for a period of one year from the date of shipment. If found to be defective during the warranty period, the product will either be repaired or replaced at Newport’s option. -
Page 4: Table Of Contents
Table of Contents Warranty ....................... ii Table of Contents ....................iii List of Figures ...................... iv Specifications ...................... iv Section 1 — General Information Introduction .....................1 Getting Started ..................1 Unpacking and Inspection ..............1 Safety Considerations ................1 Warranty Information ................3 Options and Accessories ...............3 Section 2 —... -
Page 5: List Of Figures
8 ft × 22.6 in (244 × 57.5 cm) ATS-8: 10 ft × 22.6 in (305 × 57.5 cm) ATS-10: System Weight: 225 lbs. (102 Kgs) — ATS-10 System Height: 66.0 in (167.6 cm) Adjustable: 60.6–66.0 in (153.9–167.6 cm) System Width: Shelf: 26.0 in (66.0 cm) -
Page 6: Section 1 - General Information
Shelf system. The components have been partially assembled at the factory and require only final assembly. Unpacking and In- The components of the Newport ATS Shelf Systems are packed in indi- spection vidual, labeled boxes. Be sure the number of boxes you received is equal to the total number listed on the label (for example, if a box is labeled 1 of 4, there should be 4 boxes). - Page 7 Figure 1.1 — ATS Shelf System...
-
Page 8: Warranty Information
Warning The ATS Shelf System is a metallic electrical conductor. To prevent the possibility of electrical shock, be sure that all equipment is properly insulated and grounded before placing it on the shelf system. Your ATS Shelf System is equipped with an approved three-wire, grounded power cord. -
Page 9: Prepare For Assembly
Assembly Prepare For Assembly The Newport ATS Shelf System is assembled in the inverted position and placed upright afterward. Before you begin, place a sheet of cardboard or foam on the floor where you will be assembling the system. To prevent damage to the ends of the shelf and the electrical outlets, be sure the sheet is larger than the shelf. - Page 10 * Center Support 5/16-18 Bolt, Rail 2 Washers, 1 Nut, 2 Places Shelf Bracket, 2 Places 5/16-18x3/4 Bolt, Washer, Nut 8 Places Figure 2.2 — Install Shelf Brackets E. On systems longer than 6 feet (or 2 meters), fasten each bracket to -18 ×...
- Page 11 Base Support, 2 Places 5/16-18 x 5/8 Bolt, 1 Washer, 2 Places 5/16-18 x 3/4 Bolt, 1 Washer, 2 Places Vertical Support Post, 5/16-18 x 3/4 Bolt, 2 Places 2 Washers, 1 Nut, 12 Places 5/16-18 x 3/4 Bolt, 2 Washers, Nut, 12 Places NOTE: Center support rail is not used on systems with a length of...
-
Page 12: Verify Assembly
110 VAC at 15 Amps. Warning The AC power cords supplied with the ATS System have a grounded, three-wire plug to prevent injury from electrical shock. Do not defeat this feature by removing the round pin. Doing so could result in hazardous electric shock. -
Page 13: Section 3 - Operation
Section 3 Operation Principles of The Newport ATS Shelf System provides a convenient support and storage Operation shelf for measurement equipment and power supplies that should be located off of the optical table. The two power strips provide a ready source of AC power for equipment located on the shelf as well as on the table. -
Page 14: Electrical Loading
Some equipment, such as motors and power supplies, have an initial surge current that exceeds the nominal operating current. This surge current may cause failure of the ATS power switch if it is used to control several devices where the total surge current substantially exceeds the 15 amp rating of the switch. -
Page 15: Mechanical Stability
(135 Kgs) distributed. Electrical Failures If equipment plugged in to the ATS Shelf power strips fails to function, use the following procedure to locate and correct the problem: A. Be sure the ATS power switch is turned ON. This rocker switch will be illuminated when in the ON position. -
Page 16: Section 5 - Factory Service
2. Purchase order number. 3. Complete description of the problem. If components are to be returned to Newport Corporation, you will be given a Return Number, which you should reference in your shipping documents. Please fill out the service form located on the next page, and have the information ready when contacting Newport Corporation. -
Page 18: Service Form
Service Form Vibration Control Products Newport Corporation U.S.A. Office: 949/863-3144 FAX: 949/253-1800 Name RETURN AUTHORIZATION # ________________________________________________________________________ _________________________________ Company (Please obtain prior to return of item) __________________________________________________________________ Address _____________________________________________________________________ Country Date ____________________________________________________________________ _____________________________________________________________________ P.O. Number Phone Number _______________________________________________________________ _____________________________________________________ Item(s) Being Returned:... - Page 20 Notes:...
- Page 21 Irvine, CA 92606 (In U.S.): 800-222-6440 Tel: 949-863-3144 Fax: 949-253-1680 Internet: sales@newport.com Visit Newport Online at: www.newport.com Newport Corporation, Irvine, California, has P/N 16951-01 Rev G been certified compliant with ISO 9001 by the British Standards Institution. Printed in the USA...
