- Page 1 R.A.C.E. STATION ™ USER’S MANUAL Original User Manual 03/20...
- Page 2 Failure to follow these instructions could result in property damage, personal injury, or death. NOTE Read and follow all instructions within the user manuals of any other optional equipment or accessories used in conjunction with the R.A.C.E. Station ™...
-
Page 3: Table Of Contents
TABLE OF CONTENTS HOW THE R.A.C.E. STATION WORKS ................2 ™ FOR YOUR SAFETY ......................3 R.A.C.E. STATION PARTS AND ACCESSORIES ..............4 ™ R.A.C.E. STATION SPECIFICATIONS ................5 ™ PRODUCT INFORMATION ....................6 OPTIONAL ACCESSORIES ....................7 LION SERVICE PLANS ....................... 8 OPERATING INSTRUCTIONS .................... -
Page 4: How The R.a.c.e. Station Works
™ HOW THE R.A.C.E. STATION WORKS ™ Congratulations on the purchase of your new R.A.C.E. Station ™ This state-of-the-art training tool uses a pull station, annunciator and extinguisher sensor to facilitate complete “R.A.C.E.-to-P.A.S.S.” training in conjunction with the LION BullsEye Digital Fire Extinguisher Training System. -
Page 5: For Your Safety
Failure to follow this manual’s WARNINGS and instructions can result in severe personal injury, death, or property damage. LION is not responsible for any damage, death, or injury that may arise or result from improper or misuse of the R.A.C.E. Station ™... -
Page 6: Station Parts And Accessories
R.A.C.E. STATION ™ R.A.C.E. STATION PARTS AND ACCESSORIES PARTS LIST To order replacement parts, contact your distributor or LION for assistance. WWW.LIONPROTECTS.COM... -
Page 7: Station ™ Specifications
R.A.C.E. STATION SPECIFICATIONS ™ PHYSICAL SPECIFICATIONS 44.3” x 25” x 16.5” Kit Case Dimensions (112.40 cm x 63.5 cm x 41.91 cm) 104 lbs. (47.3 kg) OR 120 lbs. (54.5 kg) Kit Case Weight with added optional ECO Kit Case Transport Features... -
Page 8: Product Information
1. Strobe Annunciator/Residential 3. Extinguisher Bracket/Sensor 2. Single Action Pull (or Push) Station 4. Electric Cutoff Switch TRIPODS TO HOLD THE R.A.C.E. STATION PROP BOXES ™ Each R.A.C.E. Station Prop Box includes its own tripod. The tripods are quick ™... -
Page 9: Optional Accessories
WIRELESS QI CHARGER (NOT SHOWN) The Interactive Emergency Phone features wireless charging capability. Set the phone on this stand and it will begin charging. MULTIPORT USB 12VDC POWER SUPPLY(S) (NOT SHOWN) Included with each R.A.C.E. Station are two Multiport USB power supplies. ™ •... -
Page 10: Lion Service Plans
LION immediately to report any concerns. 8.1.1 SETTING UP THE R.A.C.E. STATION ™ 1. Do NOT use the R.A.C.E. Station without reading the entire User’s Manual first. ™ 2. Review training location and plan where the Network Bridge and Stationary props will be setup. - Page 11 3. Setup the LION Network Bridge Adapter as provided with your R.A.C.E. Station ™ 1. To setup this prop, simply plug the Network Bridge Adapter into power with the provided USB charger and USB C cable. It should quickly turn on, and the Link/Status indicator should illuminate solid green.
- Page 12 R.A.C.E. STATION ™ 6. To power on the prop, simply hold the power button until all four vertical indicators illuminate, and then release the power button. At this point, the prop should be ready for training. 1. The status indicators will now indicate the level of charge of the internal batteries.
- Page 13 8.1.2 RUNNING TRAINING EVOLUTIONS WITH YOUR R.A.C.E. STATION 2.0 ™ 1. Before training, observe that all props are connected and in their correct initial state. i. Observe that every prop has a green link status indicator. ii. Observe that the bridge has each of the prop status indicators illuminated, for every prop being used in training.
- Page 14 ™ Training System as instructed in the provided User Manual 2. Setup your Electrical Cutoff prop and your LION Network Bridge adapter according to the operating instructions in section 8.1.1, with special care to ensure that the Network Bridge is within 10 meters of the ATTACK or BullsEye Panel.
- Page 15 8.2 CHARGING YOUR BATTERY POWERED R.A.C.E. STATION PROPS ™ To charge your R.A.C.E. Station props, simply plug them into the provided power ™ supply with the provided USB C cables. The stationary props will indicate that they are charging by blinking each battery indicator in an escalating pattern, see figure 11.
- Page 16 R.A.C.E. STATION ™ 8.3.2 CHANGING THE EMERGENCY MESSAGE ON THE TRAINING PHONE PROP The training phone prop will always have a default emergency message that can be used, but a new message can be recorded directly on the phone and selected instead.
- Page 17 4. The strobe brightness is set using the slider on the bottom back of the annunciator. The setting is shown in a small window on the front of the annunciator below the strobe. Use only the 15 or 15/75 settings with the R.A.C.E. Station . The strobe ™...
- Page 18 R.A.C.E. STATION ™ 8.4 SETTING OPTIMAL DISTANCE BETWEEN PROPS Having the props setup and within operating range will help alleviate most of the errors listed in the troubleshooting section. Use the chart below along with the details outlined in section 8.1.1, step 2 to optimize setup.
- Page 19 8.5 TROUBLESHOOTING 8.5.1 ALL PROP LINK INDICATORS ARE SOLID RED This means that your network bridge adapter is not powered on, not in range, or it is malfunctioning. Make sure that it is powered on, its link indicator is solid green, and it is within range of the other props.
-
Page 20: Shutdown/Put Away Procedure
® 10. MAINTENANCE INSTRUCTIONS GENERAL MAINTENANCE Store the R.A.C.E. Station and accessories in a cool, dry area when not in use. ™ The residential fire alarm does use a standard battery, which will beep when it is close to its lifespan and needs to be replaced. -
Page 21: Warranty Information
Labor related to warranty repair is covered free of charge during the warranty period. Repair work, however, requires the prior approval of an authorized company official. Labor costs to the account of LION are based on a predetermined rate schedule and any repair work must be done through an authorized LION dealer. - Page 22 R.A.C.E. STATION ™ After the first year, LION will not be responsible for replacement part expense, installation, labor or any other costs or expenses related to the reinstallation of a replacement part, and such expenses are not covered by this warranty.
-
Page 23: Contact Information
12. CONTACT INFORMATION LION North America | South America 7200 Poe Avenue, Suite 4000 Dayton, OH 45414, U.S.A. info@lionprotects.com 800-548-6614 (PPE) 888-428-5539 (Training) Europe | Middle East | Asia Industrieweg 5, 5111 ND Baarle-Nassau, The Netherlands infoEMEA@lionprotects.com 0031-13-507-6800 WWW.LIONPROTECTS.COM... - Page 24 WWW.LIONPROTECTS.COM Manufactured in the USA © LION Group, Inc. All rights reserved.
