- Page 1 ASIA TILLING ROTARY & ROTARY TILLER OPERATING MANUAL & PARTS LIST TR-60 / RT-60...
- Page 2 Contents Contents 1. Rotary tiller ----------------------------------------- 3 2. Tilling Rorary -------------------------------------- 4 TR-60, RT-60...
- Page 4 [Fig.1]. Fig.9-1 4) The working point of rotary tiller ① Working at rotary, please prevent the approaching of the person in front of machine. ② After work at rotary, the leveling works in [Reverse 1st] TR-60, RT-60...
- Page 5 [Fig.2]. wheel support ② Wet paddy tilling rotor(option) Remove the wheel(rubber), and exchange the steel wheel like [Fig.3]. Disassemble the tail wheel adjust handle and assemble revolving tail wheel ass’y as shown in [Fig.4]. Fig.9-4 TR-60, RT-60...
- Page 6 Important ■ As the rotary working, lift the handle when the wheel of machine is slipped and press the handle when the machine goes to forward lightly, following to the soil condition and working depth. TR-60, RT-60...
- Page 7 2) Turn to reverse the handle, work 2) Steel wheel set above. tilling to tilling rotor in the same way. rotor 3) Revolving tail (Turn to reverse 3) Rotary work in wet paddy, refer to work wheel set the handle) [Fig.6]. TR-60, RT-60...
- Page 8 THE ASIA PARTS LIST Never use other than GENUINE ASIA PARTS they are standardized, tested and proved. Using genuine parts saves your time and money above all. Ensures that your machine will always be ready for immediate work.
- Page 10 CONTENTS Group Description Page AB010 Tilling Rotor (TR-60) AB070 Rotary Tiller (RT-60)
- Page 11 B010 10 11 TR-6...
- Page 12 ASIA PARTS LIST AB010 Tilling Rotor (TR-60) 2017.10. Parts No. Size Parts Name Q’ty Remarks TR-1001 Blade(L), Rotary TR-1002 Blade(R), Rotary TR-1003 Special Blade(L), Rotary TR-1004 Special Blade(R), Rotary AB010-10051-01 Tube(L), Rotary AB010-10061-01 Tube(R), Rotary DT-0708 Setting bolt A163-10Z M10P1.5...
- Page 13 B070 10 11 RT-6...
- Page 14 ASIA PARTS LIST AB070 Rotary Tiller (RT-60) 2017.10. Parts No. Size Parts Name Q’ty Remarks TR-1001 Blade(L), Rotary TR-1002 Blade(R), Rotary TR-1003 Special Blade(L), Rotary TR-1004 Special Blade(R), Rotary AB010-10051-01 Tube(L), Rotary AB010-10061-01 Tube(R), Rotary DT-0708 Setting bolt M10P1.5 A163-10Z DT-0720 Bolt, Blade setting A204-10Z...
- Page 15 ASIA TILLING ROTOR & ROTARY TILLER TR-60 / RT-60 Mailing Add. : R.M.701, SHIN TAE YANG BLDG. 736-8, BANPO-DONG, SEOCHO-GU, SEOUL, KOREA 137-810 http://www.asiakor.com TEL : 02) 547-8098 FAX : 02) 547-0989 NO.1710...
