ETP 5660
DE AT BE GB FR NL IT GR SE NO FI DK
HOB MOUNTING DIMENSIONS (mm)
5019 419 61521/A
PRODUCT DESCRIPTION SHEET
1.
Front left cooking zone,
180 mm, 1700 W, 230 V
2.
Rear left cooking zone
210 mm, 2100 W, 230 V
3.
Rear right cooking zone
145 mm, 1200 W, 230 V
4.
Front right cooking zone
145 mm, 1200 W, 230 V
5.
Display
Important:
To avoid permanently damaging the glass-
ceramic top, do not use:
- Pots with bottoms that are not perfectly
flat.
- Metal pots with enamelled bottom.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bauknecht ETP 5660
Summary of Contents for Bauknecht ETP 5660
- Page 1 ETP 5660 PRODUCT DESCRIPTION SHEET DE AT BE GB FR NL IT GR SE NO FI DK Front left cooking zone, 180 mm, 1700 W, 230 V Rear left cooking zone 210 mm, 2100 W, 230 V Rear right cooking zone...
- Page 2 USING THE HOB The button must be pressed for about 2 sec. to switch the hob on. The indication “0” appears in area A on the 4 displays. If within about 25 sec. none of the cooking zones is activated, the hob switches itself off automatically on safety grounds. Choose the button for the desired cooking area and press it.
- Page 3 The CHILD SAFETY function is switched on with this button and indicated by an additional red control LED. With the exception of the hob’s On and Off buttons, all other buttons are locked. This function remains on even after the hob has been switched off and on again and can be cancelled by pressing the button again for 2 seconds.
