OUT3N
RAW_DATA
RX
OUT3N and RAW_DATA (Test Register is Set to 0x19) for BPSK Pattern
The following table summarizes key test codes for configuring the Test[6:0] bit field (Sector0-0x3A.[6:0]) to route
internal key signals to monitor for adjustment of the above parameters. While the meanings of such signals are
explained in the accompanying "Meaning of Key Test Signal" table.
Test[6:0] TDSelect Bit
(Hex) (Sector0-0x39.3)
0x0E 0
0x10 0
0x11 0
0x12 0
0x13 0
0x19 1
0x1C 1
0x1E 0
0x1F 0
0x4D 0
Signal
OUT3P A positive phase amplified output from the 3rd state amplifier
OUT3N A negative phase amplified output from the 3rd state amplifier
An integrated output from Manchester decoder
VRECT The last value of VRECT is used to evaluate the output bits together with Minlevel and
CollLevel
RESET_INT Signal indicating new slots used in Manchester decoder
CORR_S_VALID Validity of output data from Manchester decoder
CORR_S_COLL Collision of output data from Manchester decoder
CORR_S_DATA Evaluate output data from Manchester decoder
BPSK_DATA BPSK pattern recovery signal from DPLL
S_DATA Evaluate output data from Machester / BPSK decoder, feeding to frame decoder
S_VALID Validity of output data from Manchester / BPSK decoder, feeding to frame decoder
RAW_DATA RX Amplifier - comparator output, converting analog signal into digital signal
Rev. 1.20
TD Related Block
CORR_S_DATA Manch/FSK decoder
RESET_INT Manch/FSK decoder
BPSK_DATA BPSK Decoder
S_VALID BPSK Decoder
S_DATA Manch/FSK/BPSK decoder OUT3P
RAW_DATA RX Amplifier
MANCH_WO_SUB Manch/FSK decoder
CORR_S_VALID Manch/FSK decoder
CORR_S_COLL Manch/FSK decoder
TX_EN Transmitter
Key Test Signal and Indication
91
Pins
TA
VRECT Manch/FSK decoder
OUT3P RX Amplifier
OUT3P RX Amplifier
OUT3P RX Amplifier
RX Amplifier
OUT3N RX Amplifier
VRECT Manch/FSK decoder
VRECT Manch/FSK decoder
VRECT Manch/FSK decoder
VRECT Manch/FSK decoder
Description
BC45B4523
Related Block
