- Page 1 USER GUIDE EZ Switch 10/100 16/24-port SMC-EZ1016DT Unmanaged Fast Ethernet Switch SMC-EZ1024DT...
- Page 2 Information furnished by LG-Ericsson USA, Inc. is believed to be accurate and reliable. However, no responsibility is assumed by LG-Ericsson USA, Inc. for its use, nor for any infringements of patents or other rights of third parties, which may result from its use. No license is granted by implication or otherwise under any patent or patent rights of LG-Er- icsson USA, Inc.
- Page 3 Warranty and Product Registration To register LG-Ericsson products and to review the detailed warranty statement, please refer to the LG-Ericsson Website at http://www.lgericssonus.com...
- Page 4 OMPLIANCES FCC - Class A Federal Communication Commission Interference Statement This Equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
- Page 5 RFI Emission: Limit class A according to EN 55022:2006 (EMC) • Limit class A for harmonic current emission according to EN • 61000-3-2/2000+A2:2005 Limitation of voltage fluctuation and flicker in low-voltage • supply system according to EN 61000-3-3/1995+A1:2001+A2:2005 Immunity: Product family standard according to EN •...
- Page 6 VCCI - Class A この装置は、情報処理装置等電波障害自主規制協議会（VCCI）の基準に基づくク ラスA情報技術装置です。この装置を家庭環境で使用すると電波妨害を引き起こ すことがあります。この場合には使用者が適切な対策を講ずるよう要求されることが あります。 Please read the following safety information carefully before installing the Switch: WARNING: Installation and removal of the unit must be carried out by qualified personnel only. This guide is intended for use by network administrators who •...
- Page 7 France and Peru only This unit cannot be powered from IT. supplies. If your supplies are of IT type, this unit must be powered by 230 V (2P+T) via an isolation transformer ratio 1:1, with the secondary connection point labelled Neutral, connected directly to earth (ground).
- Page 8 Veuillez lire à fond l’information de la sécurité suivante avant d’installer le Switch: AVERTISSEMENT: L.installation et la dépose de ce groupe doivent être confiés à un personnel qualifié. Ne branchez pas votre appareil sur une prise secteur • (alimentation électrique) lorsqu’il n’y a pas de connexion de mise à...
- Page 9 Cordon électrique - Il doit être agréé dans le pays d.utilisation Etats-Unis et Le cordon doit avoir reçu l′homologation Can-ada: des UL et un certificat de CSA. Les spe’cifications minimales pour la corde flexible sont AWG No. 18, ou AWG No. 16 pour une longueur infe’rieure a‘...
- Page 10 Bitte unbedingt vor dem Einbauen des RPU die folgenden Sicherheitsanweisungen durchlesen: WARNUNG: Die Installation und der Ausbau des Geräts darf nur durch Fachpersonal erfolgen. Diese Anleitung ist fr die Benutzung durch • Netzwerkadministratoren vorgesehen, die fr die Installation und das einstellen von Netzwerkkomponenten verantwortlich sind;...
- Page 11 Warnings and Cautionary Messages Warning: This product does not contain any serviceable user parts. Warning: Installation and removal of the unit must be carried out by qualified personnel only. Warning: When connecting this device to a power outlet, connect the field ground lead on the tri-pole power plug to a valid earth ground line to prevent electrical hazards.
- Page 12 Environmental Statement The manufacturer of this product endeavors to sustain an environmentally-friendly policy throughout the entire production process. This is achieved though the following means: Adherence to national legislation and regulations on • environmental production standards. Conservation of operational resources. •...
-
Page 13: Table Of Contents
ABLE ONTENTS INTRODUCTION ........2 Green Saving Switches…………………………………………….2 Features and Benefits ........2 Front Panel LEDs ..........4 Front Panel ............4 Rear Panel ............4 INSTALLING THE SWITCH ....5 Package Contents ..........5 Selecting a Site ..........5 Instructions ............. -
Page 14: Introduction
NTRODUCTION The EZ Switch™ 10/100 SMC-EZ1016DT and SMC-EZ1024DT are 16/24-port Fast Ethernet switches. The 10BASE-T/100BASE-TX ports deliver dedicated 10/100 Mbps links to each attached LAN segment – all with conventional cabling and adapters. Auto-negotiation is used to select the optimal communication mode for each connection. -
Page 15: Features And Benefits
Features and Benefits Save up to 59% of power usage with the • SMC-EZ1016DT/SMC-EZ1024DT switches - If PCs connected to the switches are turned off, the switches can save up to 59% for the power used. And even under full traffic load, the switches can still save up to 21% power consumption. -
Page 16: Front Panel Leds
Front Panel LEDs The front panel of the switch provides a link status LED for each RJ-45 port. In addition, the front panel also contains status LEDs for “at-a-glance” system monitoring. The following table details the functions of the various indicators: Port and Switch Status LEDs Condition Status... -
Page 17: Installing The Switch
NSTALLING THE WITCH Before installing the switch, verify that you have all the items listed under “Package Contents.” Note that the switch can be installed on any suitably large flat surface or in a standard EIA 19-inch rack. Package Contents The EZ Switch 10/100 includes: EZ Switch 10/100 (SMC-EZ1016DT or SMC-EZ1024DT) •... -
Page 18: Instructions
Instructions 1. Positioning the Switch: For desktop or shelf mounting, attach the four adhesive foot pads to the bottom of the switch. For rack mounting, install into a standard EIA 19-inch rack using the included brackets. 2. Applying Power: Plug one end of the power cord into the socket on the switch’s rear panel, and the other end into an appropriate electrical outlet. -
Page 19: Troubleshooting
ROUBLESHOOTING Diagnosing Switch Indicators 1. Symptom Power LED does not light after power on. Probable Causes AC power cord may be defective. Possible Solutions Check for loose connections. Check the power outlet by using it for another device. Replace the AC power cord. 2. -
Page 20: Cables
ABLES Cable Specifications Cable Types and Specifications Cable Type Max. Length Connector 2-pair Cat. 3 or better 10BASE-T 100 m (328 ft) RJ-45 100-ohm UTP 2-pair Cat. 5 or better 100BASE-TX 100 m (328 ft) RJ-45 100-ohm UTP 10BASE-T/100BASE-TX Pin Assignments Caution: DO NOT plug a phone jack connector into any RJ-45 port. -
Page 21: Product Specifications
PRODUCT SPECIFICATIONS EZ Switch 10/100 Standards IEEE 802.3-2002 Conformance Ethernet, Fast Ethernet Full-duplex flow control Communication Rate 10 and 100Mbps Communication Mode Full or half duplex at 10/100 Mbps Media Supported 10BASE-T: 100-ohm Category 3 or better twisted-pair 100BASE-TX: 100-ohm Category 5 or better twisted pair Number of Ports SMC-EZ1016DT: 16 RJ-45 10/100... - Page 22 Information furnished by LG-Ericsson USA, Inc. is believed to be accurate and reliable. However, no responsibility is assumed by LG-Ericsson USA, Inc. for its use, nor for any infringements of patents or other rights of third parties, which may result from its use.
