Fuji Electric ZDL05 Quick Start Manual

NO / NO Converter
2
Model: ZDL05
Preface
We thank you very much for purchasing Fuji's NO
Converter.
● Please read this instruction manual thoroughly before installing,
using and applying maintenance this device.
Damage or accident may be caused when mishandled.
● Specification of this NO
notice for modification.
● Do not remodel or modify this NO
manufacturer's permission. Fuji Electric will not accept any
liability whatsoever for any trouble or accident caused by such
modification.
● Operator of the NO /NO converter should keep this instruction
2
manual.
● Operator should keep this instruction manual near at hand at all
times, after thoroughly reading it.
Safety precautions
Please read the safety precautions written as bellow before
use, for correct use of the converter.
Please observe cautions stated bellow, for it contains important
information on safety.
Precautions under this mark is stated
when wrong handling may cause
hazardous situation. Possibility of
CAUTION
Medium level damage or injury, and
physical damage is predicted.
CAUTION
Installation, wiring and piping should be carried out by
●
professionals or suppliers. Incomplete installation may cause
fall of the device, electric shock or fire.
Gas analyzer should be turned OFF when wiring, maintenance
●
or inspection is carried out. This is to prevent electric shock and
injury.
Use wires with proper wire rods and diameters that meets this
●
device. Wrong ones may cause electric shock or fire.
Do not insert metal rod or fingers to the power supply terminal.
●
It may cause electric shock.
Remove any metal objects such as wristwatch while operating
●
maintenance or inspection. It may cause electric shock.
Use pipes with proper material and joints stated in the
●
instruction manual. It may cause gas leakage.
Use replacement parts that are specified by the manufacturer.
●
Otherwise, it may cause malfunction, electric shock or gas
leakage.
Do not touch the converter section, due to high temperature.
●
Wear protective gloves while exchanging catalyst. It may cause
burn injury.
INSTRUCTION MANUAL
INZ-TN1ZDL05-E
/NO converter may alter without
2
/NO converter without the
2
Global Sales Section
Instrumentation & Sensors Planning Dept.
1, Fuji-machi, Hino-city, Tokyo 191-8502, Japan
http://www.fujielectric.com
Phone: +81-42-514-8930 Fax: +81-42-583-8275
http://www.fujielectric.com/products/instruments/
/NO
2
The NO /NO converter is to be coupled with a NOx gas
2
analyzer or NH
converter using a special catalyst which efficiently
converts NO in sample gas to NO.
2
2. Major Specifications
Catalyst
Gas flow rate
Set temperature
Thermocouple
Power supply
Power consumption : About 85VA
Altitude
Installation category : II
Pollution Degree
Gas inlet/outlet connection method:
Insert Teflon tube ø6 mm/ø4 mm into Viton
connection port of inner diameter ø5.5 mm.
(Withstand pressure: 10 kPa)
Contact output
3. Outline Drawing
This gas converter is composed of the converter and the
temperature controller.
148
135
124
Contact output (1b)
220V AC
30V DC, 1A
FRONT VIEW
1. Overview
gas analyzer for flue exhaust. It is
3
: Carbon, replacement, required
every 8 months
(when NO concentration is 10
2
ppm or lower)
: About 0.5L/min.
: 220±10°C
: K
: 100 to 240V AC, 50/60Hz
: Up to 2,000 m
: 2
: for temperature alarm
SPST-NC contact, 220 V AC / 30
V DC, 1A (resistive load)
Maintenance space
(Upper side)
O UT L E T
(NP)
(NP)
I NT L ET
4-ø4.5
Earth terminal
Power supply
terminal
100 to 240V AC
(Lower side)
Maintenance space
RIGHT SIDE VIEW
Fig. 1 Outline drawing
130
Outlet
ø9.5/5.5
(VITON)
Inlet
ø9.5/5.5
(VITON)
