Instruction Sheet
Kit Numbers: 79106700, 79105700, 79105800 & 79105900
44", 48", 52" & 60" MULCH KIT
WARNING: FAILURE TO FOLLOW
INSTRUCTIONS could result in personal injury
and/or damage to unit.
Read, understand, and follow all safety practices
in Operator's Manual before beginning.
Package Contents
Check the contents of your kit for the parts listed below.
Also see Figure 1.
IMPORTANT: 60" mulch kit shown; other kits similar.
Item
Description
79106700 – 44-Inch Mulch Kit
1.
Right Baffle
2.
Left Baffle
3.
Discharge Baffle
4.
Mulching Blade – 16 1/4"
79105700 – 48-Inch Mulch Kit
1.
Right Baffle
2.
Left Baffle
3.
Discharge Baffle
4.
Mulching Blade – 16 1/4"
79105800 – 52-Inch Mulch Kit
1.
Right Baffle
2.
Left Baffle
3.
Discharge Baffle
4.
Mulching Blade – 52"
79105900 – 60-Inch Mulch Kit
1.
Right Baffle
2.
Left Baffle
3.
Discharge Baffle
4.
Mulching Blade – 60"
Mounting Hardware – All Kits
5.
5/16"-18 x 1" Round Head
Square Neck Bolt
6.
5/16"-18 x 1" Hex Bolt
7.
5/16-18" Nyloc Flange Nut
Copyright 2017 • Ariens Company • Brillion, WI 54110
Qty Ariens P/N
1
05108151
1
05108251
SPECIAL TOOLS REQUIRED
1
04531351
3
00273000
1
05107951
1
05108051
REMOVAL
1
04560051
3
00273000
1.
2.
1
05107751
1
05107851
1
04526851
3.
3
04887600
4.
1
05107551
1
05107651
1
04526551
3
04887700
4
06200231
2
05901701
8
06500809
6
5
3
1
Figure 1
• Drill (For some 52" decks)
• Center Punch (For some 52" decks)
• 11/32" Drill Bit (For some 52" decks)
Park unit on a flat level surface and engage parking
brake.
Stop engine, remove key and wait for moving parts
to stop and for hot parts to cool.
Disconnect spark plug wires.
Remove hardware retaining discharge chute
assembly and remove chute assembly. Retain parts
for operation without mulch kit. See Figure 2.
Figure 2
08400386B • 11/17 • Page 1 of 4
7
4
2
Advertisement
Related Manuals for Gravely 79106700
Summary of Contents for Gravely 79106700
- Page 1 Instruction Sheet Kit Numbers: 79106700, 79105700, 79105800 & 79105900 44", 48", 52" & 60" MULCH KIT WARNING: FAILURE TO FOLLOW INSTRUCTIONS could result in personal injury and/or damage to unit. Read, understand, and follow all safety practices in Operator’s Manual before beginning.
- Page 2 Remove tapping screws from deck and retain for For models equipped with front vacuum baffles and operation without mulch kit. See Figure 3. / or discharge baffle, remove hardware retaining baffles and remove baffles. Retain parts for operation without mulch kit. See Figure 5. Figure 3 CAUTION: AVOID INJURY! Use sturdy gloves or padding to protect hands when working with...
- Page 3 See Figure 7. Secure discharge baffle (item 3) to deck with two 5/16" nyloc flange nuts. See Figure 9. IMPORTANT: Some 52" decks require drilling a hole through the deck above the top hole in right baffle. If applicable, continue to step 2. If not, advance to step 5. Ensure right baffle mounting hardware is tight.
- Page 4 MULCHING TIPS Mow at full throttle and half speed. Mow dry grass only. Keep mower blades sharp. Cut no more than 2.5 cm (1") at one time. For tall grass, mow at a higher cutting height, then make a second or third pass with the deck set to the desired cutting height.
