- Page 1 Page 1 Angustos – Desktop KVM User Manual User Manual Desktop KVM switch series VGA Series : AD-V21L/ AD-V41L DVI Series : AD-D21L/ AD-D41L HDMI Series : AD-H21L/ AD-H41L Display Port Series : AD-DP21L/ AD-DP41L Multi-Channel HDMI Series : AD-H22L/ AD-H42L...
- Page 2 Page 2 Angustos – Desktop KVM User Manual NOTE US Federal Communications Commission Interference Statement This product has been tested and found to comply with rules in Section 15 of the FCC Rules Class B (Class B) digital device and FCC specifications. These specifications are intended to be used in a commercial environment, to protect them from harmful interference, and to provide effective protection.
- Page 3 Page 3 Angustos – Desktop KVM User Manual User considerations The manufacturer has the right to modify and change the information, documents and specifications contained in the manual without prior notice. The manufacturer does not warrant, express, imply or statutorily declare its contents or specifically disclaims its merchantability and fitness for a particular purpose.
- Page 4 Page 4 Angustos – Desktop KVM User Manual Product model description: Model Configuration instructions AD-V21L 2 groups of controlled interface VGA+ audio +MIC+USB (keyboard, mouse, USB flash drive, printer, etc.), a set of local control interface, a front USB interface, support hotkey switching and panel button switching control.
- Page 5 Page 5 Angustos – Desktop KVM User Manual AD-H41PL 4 sets of controlled terminal interfaces HDMI + audio + MIC + USB (keyboard, mouse, U disk, printer, etc.), one set of local control terminal interfaces, one front USB interface, 2 front USB3.0 interfaces, support hotkey switching And panel keys switch control.
-
Page 6: Table Of Contents
Page 6 Angustos – Desktop KVM User Manual Contents About this manual ⚫ Common language description ⚫ Chapter One ⚫ Introduction ⚫ Product description ⚫ Product Features ⚫ Operating system ⚫ Component ⚫ Front view ⚫ Rear view ⚫ Chapter two ⚫... -
Page 7: About This Manual
Page 7 Angustos – Desktop KVM User Manual About manual This User Manual will assist you in the effective use of product features, including the installation, setup, and operation of your equipment. You can find out what is included in this manual from the following: Chapter One: Introduction –... -
Page 8: Introduction
Page 8 Angustos – Desktop KVM User Manual Chapter I Introduction Product description As a KVM switch, The KVM switches allows users to access from a single console station with keyboard, mouse, and VGA, DVI, HDMI, DP display to access 2/4 computers. -
Page 9: Operating System
Ubuntu 7.04/7.10 UNIX 4.3 or higher FreeBSD 5.5 or higher Sun Solaris 8 or higher OS 9.0 to 10.6 (Snow Leopard) Novell Netware 6.0 or higher Components front view AD-V21L / AD-D21L / AD-DP21L/ AD-DP22L / AD-H21L / AD-H22L AD-V41L/AD-D41L/AD-DP41L/AD-DP42L/AD-H41L/AD-H42L... - Page 10 Page 10 Angustos – Desktop KVM User Manual AD-H21PL AD-H41PL AD-H22PL AD-H42PL...
-
Page 11: Rear View
Page 11 Angustos – Desktop KVM User Manual Rear view AD-V21L AD-H41L AD-D21L AD-D41L... - Page 12 Page 12 Angustos – Desktop KVM User Manual AD-H21L AD-H41L AD-H22L AD-H42L...
- Page 13 Page 13 Angustos – Desktop KVM User Manual AD-DP21L AD-DP41L AD-DP22L...
- Page 14 Page 14 Angustos – Desktop KVM User Manual AD-DP42L AD-H21PL AD-H41PL AD-H22PL...
- Page 15 Page 15 Angustos – Desktop KVM User Manual AD-H42PL Power input port – Back up power port for user to connect Power Adapter in case power from USB is not provided. Please use the correct voltage adapter to prevent short circuit.
- Page 16 Page 16 Angustos – Desktop KVM User Manual Local display VGA output interface KVM port interface, it must connected to the dedicated KVM cable provided with the KVM Switch. For DVI video interface For HDMI video interface For DP video interface...
-
Page 17: Hardware Installation
Page 17 Angustos – Desktop KVM User Manual Chapter II Hardware installation Cable connection and installation KVM switches can be placed on any stable surface and is sufficient to support the weight of the device plus the additional cables. Clean and make sure that no other plane debris would affect the switch ventilation and normal operation. -
Page 18: Basic Operation
Page 18 Angustos – Desktop KVM User Manual Chapter III Basic operation Overview There ways the KVM switch change port connected computer: Combination hotkey on the USB keyboard or the manual switch operation on the front of the KVM device. -
Page 19: Keyboard Port Operation
Page 19 Angustos – Desktop KVM User Manual Chapter IV Keyboard operation Overview The KVM product in this desktop series offers many easy hotkey operations, making it easy to set up KVM via the keyboard or to complete port switching. - Page 20 Page 20 Angustos – Desktop KVM User Manual 2.[ SCROLL 】 + [ SCROLL ] mode Hotkey combination Description Switch to the computer corresponding 【 SCROLL 】 + 【 SCROLL 】 + 【 1 】 to the port of [ 1 ] [ 2 ] [ 3 ] [ 4 ] or [2 】...
- Page 21 Page 21 Angustos – Desktop KVM User Manual 4.[ CAPS ] + [ CAPS ] mode Hotkey combination Description Switch to the computer corresponding [ CAPS 】 + [ CAPS 】 + [ 1 】 or [ 2 to the port of [ 1 ] [ 2 ] [ 3 ] [ 4 ] 〔...
-
Page 22: Appendix
Page 22 Angustos – Desktop KVM User Manual Appendix Safety Instructions General • This product is for indoor use only. • Please read all instructions and use them for future reference. • Please follow all warnings and instructions on the device. - Page 23 Page 23 Angustos – Desktop KVM User Manual • Do not insert any objects into the machine through the slots in the casing. There is a risk of contact with dangerous voltage points or short-circuiting parts that could result in fire or electric shock.
-
Page 24: Product Specification
Page 24 Angustos – Desktop KVM User Manual Product specification Type AD-V21L AD-V41L Computer connections Port selection Front panel buttons/Hotkey Control monitor 1 x VGA DB15 blue Female port keyboard 1 x USB Type A female mouse 1 x USB Type A female... - Page 25 Page 25 Angustos – Desktop KVM User Manual Type AD-D21L AD-D41L Computer connections Port selection Front panel buttons/Hotkey Control Port monitor 1 x DVI-Dual Link white Female keyboard 1 x USB Type A female mouse 1 x USB Type A female...
- Page 26 Page 26 Angustos – Desktop KVM User Manual Features AD-H21L AD-H41L Computer connections Port selection Front panel buttons/Hotkey Control monitor 1 x HDMI Type A black Female port keyboard 1 x USB Type A female mouse 1 x USB Type A female...
- Page 27 Page 27 Angustos – Desktop KVM User Manual Features AD-H22L AD-H42L Computer connections Port selection Front panel buttons/Hotkey Control monitor 1 x HDMI Type A black Female port keyboard 1 x USB Type A female mouse 1 x USB Type A female...
- Page 28 Page 28 Angustos – Desktop KVM User Manual Type AD-DP21L AD-DP41L Computer connections Port selection Front panel buttons/Hotkey Control monitor 1 x DP Type A black Female port keyboard 1 x USB Type A female mouse 1 x USB Type A female...
- Page 29 Page 29 Angustos – Desktop KVM User Manual Type AD-DP22L AD-DP42L Computer connections Port selection Front panel buttons/Hotkey Control monitor 2 x DP Type A black Female port keyboard 1 x USB Type A female mouse 1 x USB Type A female...
- Page 30 Page 30 Angustos – Desktop KVM User Manual Features AD-H21PL AD-H41PL Computer connections Port selection Front panel buttons/Hotkey Control monitor 1 x HDMI Type A black Female port keyboard 1 x USB Type A female mouse 1 x USB Type A female...
- Page 31 Page 31 Angustos – Desktop KVM User Manual Features AD-H22PL AD-H42PL Computer connections Port selection Front panel buttons/Hotkey Control monitor 1 x HDMI Type A black Female port keyboard 1 x USB Type A female mouse 1 x USB Type A female...
-
Page 32: Warranty Conditions
Page 32 Angustos – Desktop KVM User Manual Warranty conditions The maximum compensation the company assumes does not exceed the amount paid by the customer for the product. In addition, the company does not assume any direct, indirect, special, incidental, or consequential damages resulting from the use of this product or the CD-ROM, documentation, etc.
