Angustos KVM-04 User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
LCD KVM Switch Installation Manual
LCD KVM
SWITCH
17" - 19"
user manual
Rev. 2.1
2021.02.1
8
Angustos Inc. All rights reserved. 1
ANGUSTOS INC.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KVM-04 and is the answer not in the manual?

Questions and answers

Related Manuals for Angustos KVM-04

Summary of Contents for Angustos KVM-04

  • Page 1 LCD KVM Switch Installation Manual LCD KVM SWITCH 17" - 19" user manual Rev. 2.1 2021.02.1 Angustos Inc. All rights reserved. 1 ANGUSTOS INC.

  • Page 2: Table Of Contents

    4.4.3 HOT-KEY OPTIONS .................. 11 4.4.4 SCAN SETUP ....................11 4.4.5 LCD ENERGY-SAVING SETUP ..............12 4.4.6 RESET ......................12 5 DDC FUNCTION ....................13 6 TROUBLESHOOT IT ..................13 7: LCD KVM SERIES OF PARAMETERS ............14 8：CERTIFICATION ....................15 ANGUSTOS INC.

  • Page 3: Product Characteristics

    1 x Warranty card  1 x Qualified card  1 x AC Power line - IEC C13/C14 Plug.  If any of the above items is missing or damaged, please contact your vendor。 2: LCD KVM Hardware summary : ANGUSTOS INC.
  • Page 4 2.4 Port shortcut key debug selection ： KVM OSD Interface debugging and selection port: Hotkey to enter the OSD interface, using the keyboard number key 01 （0 + 1 Combination）TO 16(1+ 6 Combination），Quickly select ports for editing and current server operations. ANGUSTOS INC.

  • Page 5: 2.5: Rear-Panel Port

    LCD KVM Switch Installation Manual The front panel button provides you with the desired port operation to select below： Model Button The narrative KVM-04 01-04 Port key01（0+1）..16(1+6) Digital combination, when the key combination, the KVM-08 01-08 effective combination time is 1 second...
  • Page 6 You need to be authenticated before you can begin to control this KVM。 Please note: when the computer is starting the process, do not switch the computer port (for example: do not press the KVM switch port selection button ANGUSTOS INC.
  • Page 7 The default hotkey is Caps Lock，But you can change the hotkey to make it easier for your application. Selectable keyboard hotkeys (KVM OSD; Num LOCK. Scroll LOCK) 4.3：KVM OSD Function interface ： 4.3.1：KVM OSD Main interface： Order key Main menu Function ANGUSTOS INC.
  • Page 8 4.3.2：KVM OSD Deputy interface： Option Function PWD SETUP 8 Bit password setting HOTKEY SETUP OSD Hotkey keyboard function key Settings SCAN TIME Scan time Setup ENERGY TIME LCD KVM Power saving time setting 4.3.3：KVM Port display： Display the Function information ANGUSTOS INC.

  • Page 9: The Password Login Window

    Shift key first, then select the corresponding letters. Edit the port number in turn, and press the up and down cursor keys or the number shortcut keys to select the corresponding port for editing. After finishing editing, ANGUSTOS INC.

  • Page 10: Hot-Key Options

    Password function is OFF. Password missing and misoperation, resulting in access to the KVM system, try the initial password 00000000. Unable to log in the system due to password error, please contact the dealer engineer。 4.4.3：KVM OSD Hot-key options： ANGUSTOS INC.
  • Page 11 Scan Time, enter, and the default is 20 seconds in the red box below. Press the left cursor key to delete the default TIME and change it to the SCAN touring TIME required by the user, which supports 255 seconds at most. ANGUSTOS INC.

  • Page 12: Reset

    When it run abnormally, which will affect the use of functions, you can enter the OSD home page, press the keyboard F6 RESET, KVM will restart the system and automatically restore all functions of KVM。 5: DDC Function ANGUSTOS INC.
  • Page 13 When switching ports, avoid moving the mouse or pressing any mouse key。  Press the Reset button on the KVM front panel (the 0+5 combination  button) to restart the KVM switcher。 The display screen has no video signal。 ANGUSTOS INC.
  • Page 14 7：17" / 19 " LCD KVM Series of parameters： Port connector USB/VGA Port number 4/8/16 Control Port Type USB/VGA The longest cable 1.8-10 Meter Resolution output See next page port select Menus, hotkeys, buttons HOTKEY Multiple hot keys ：(Scroll-Lock/ Caps-Lock/ ANGUSTOS INC.

  • Page 15: 8：Certification

    This device complies with the following specifications：EN 60950-1：2011+A2 Statement ： Industrial products are Class A products which may cause radio interference in the living environment, in which case practical action against such interference may be required。 ANGUSTOS INC.
