BARRON Exitronix CH900X Series Installation Instructions

CH900X Series

Installation Instructions

READ AND FOLLOW ALL SAFETY INSTRUCTIONS.

When using electrical equipment, basic safety precautions should always be followed including the following:

· DISCONNECT AC POWER SUPPLY BEFORE SERVICING.

· Installation and servicing of this equipment should be performed by qualiﬁed service personnel only.

· Ensure that the electrical wiring conforms to the National Electrical Code NEC?and local regulations if

applicable.

· Do not mount near gas or electrical heaters.

· Suitable for damp locations. Do not use outdoors.

· Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering by

unauthorized personnel.

· The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.

· Any modiﬁcation or use of non-original components will void the warranty and product liability.

· Do not use this equipment for other than intended use.

For -WB version:

Allow battery to charge for 24 hours before ﬁrst use.

· Use caution when servicing batteries. Battery acid can cause burns to skin and eyes. If acid is spilled on skin

or in eyes, ﬂush acid with fresh water and contact a physician immediately.

10070267

IMPORTANT SAFEGUARDS

SAVE THESE INSTRUCTIONS!

Technical Support ■ (623) 580-8943 ■ technicalsupport@barronltg.com

800-533-3948 www.barronltg.com

Table of Contents

Do you have a question about the Exitronix CH900X Series and is the answer not in the manual?

Page 1 CH900X Series Installation Instructions IMPORTANT SAFEGUARDS READ AND FOLLOW ALL SAFETY INSTRUCTIONS. When using electrical equipment, basic safety precautions should always be followed including the following: · DISCONNECT AC POWER SUPPLY BEFORE SERVICING. · Installation and servicing of this equipment should be performed by qualiﬁed service personnel only. ·...
Page 2 CH900X Series Installation Instructions Recessed Ceiling or Recessed Wall Mount (Fig. 1-4) Fig. 1 1. Position the recessed kit between joists, making sure the bar hangers are hung in the correct position. The bar hangers Bar Hangers Recessed Kit Joists should be level with the bottom of the joists.
Page 3 CH900X Series Installation Instructions Surface Ceiling, Surface Wall, or Flag Mount (Fig. 5-7) 1. Extend unswitched 24 hour AC supply of rated voltage to J-box (provided by others). Leave at least 18 inches of slack. Circuit should Fig. 5 - Surface Ceiling Mount not be energized at this time.
Page 4 CH900X Series Installation Instructions Electrical Connections Wiring Diagram All electrical connections should be made inside the Battery White J-box. Make electrical connections as follows: COMMON MAIN PCBA 120-277VAC Exit LED Indicator Black White - Common Test switch 120~277VAC Black - 120-277VAC Green - Ground Led strip -WB Version...
