Custom nasal mask
Hide thumbs Also See for Profile Lite:

Advertisement

Quick Links

Caution: US federal law restricts this device to sale by or on the order of a physician.
!
Warning: The Profile Lite mask is designed for use with CPAP and bi-level systems
recommended by your physician or respiratory therapist. Do not wear this mask unless the CPAP or bi-level
system is turned on and operating properly.
Warning: This warning applies to most CPAP devices. At low CPAP pressures, the air flow through the exhalation port
may not be enough to clear all of the exhaled gas (CO
you have exhaled. Do not block or otherwise try to seal the vent holes on the exhalation port.
Warning: The Profile Lite mask can be reformed using boiling water. Take care when handling the heated water and the
heated mask. Read all instructions before starting the procedure.
Warning: Some users may experience skin redness. If this occurs, consult your doctor.
Caution: Do not heat the mask by placing it into a microwave or conventional oven. The mask will be damaged.
Assembly: Before use, clean the mask and gel forehead spacer following the instructions below.

Step 1

Hold the mask lightly
against your face, and
slide the headstrap over
your head.
Removing the Headstrap & Mask:
Because the entire headstrap stretches, you should not need to unfasten the straps to remove the headstrap. Simply slide the mask and
headstrap over your head. If necessary, unfasten either of the neck straps.

Cleaning Instructions:

For Multi-Patient Use Reusable. Contact Respironics Customer Service department at 1-800-345-6443 to obtain the mask Disinfect-
ing instructions (order #1011138).
The instructions below are intended for Home Use.
Clean all parts of the mask and forehead spacer daily. Clean the headstrap at least once each week or more often if needed. Before
cleaning, disconnect the mask and headstrap. Fasten the hook tabs on the straps so that they don't catch other garments in the laundry.

Mask and Gel Forehead Spacer

Step 1 Hand wash the mask and spacer in warm water with a mild
dishwashing detergent. Do not use bleach, alcohol, cleaning
solutions containing alcohol, or any strong household cleaners.
Do not use cleaners containing conditioners or moisturizers.
Step 2 Rinse thoroughly. Air dry. Make sure the mask is dry before
use. Inspect the mask after cleaning. Replace the mask if any
parts are damaged or deteriorated. Replace the spacer if
any of the gel material has become exposed. Wash your face
with a mild soap and water if it has come in contact with any
exposed gel.
The Profile Lite Custom Nasal Mask and Headstrap are
intended to provide an interface for adult patients when
used with Respironics CPAP or bi-level therapy. The mask
is designed to conform to the shape of your face and
contains an exhalation port that provides a continuous leak
path in the patient circuit. This mask does not require the
use of a separate exhalation device. LATEX-FREE

Step 2

Connect the flexible tubing to the
exhalation elbow. Turn the CPAP
or bi-level system on.
Exhalation
Port
Tubing
Gel
Forehead
Spacer
Mask
Cushion
) from the mask. You may breathe in some of the air that
2

Step 3

Lie down and breathe normally through your
nose, keeping your lips closed. Unhook the
straps and gradually tighten them until the
mask has minimal leaks and fits comfortably.
NOTE: The headstrap has two sets of tabs
for better adjustment. For larger size heads,
use the black tabs. For smaller head sizes, use
the blue tabs. The extra tabs can be removed
using a pair of scissors. DO NOT overtighten
the straps. Overtightening can cause or
worsen leaks.
Use blue tab
for smaller
size heads

Headstrap

Step 1 Hand or machine wash with a standard laundry
detergent and warm water. Rinse thoroughly. Do
not use bleach.
Step 2 Line dry or machine dry at the medium heat
setting.
Slight readjustment of the straps may be needed
NOTE:
after repeated washings.
Exhalation Port
(DO NOT BLOCK)
Removable
Port Cap
Use black tab
for larger size
heads
