Before operating the unit, please read this manual thoroughly and retain it for future reference.
Model No. 201-xx
You are cautioned that any changes or modifications not expresly approved in this manual could void your authority to operate
this equipment.
The Sentido front cover has to be used together with the Sentido switch KNX or Sentido switch RS485.
The front cover enables a capacitive coupling with the Sentido switch touch sensors.
The entire surface of the Sentido front cover will become touch sensitive, enabeling you to touch the Sentido anywhere you
want.
Identitifying the parts
A
Transparant acryl window
B
Aluminium touch sensitive surface
C
Guide to fix on the Sentido switch
D
Capacitive coupling to the Sentido switch
Sentido front 2
B
A
C
D
Installation Manual
basalte is a registered trademark of Basalte bvba..
Sentido is a registered design of Basalte bvba.
KNX is a registered trademark of the KNX organisation.
© 2008 basalte
