PROGRAMMING

FAN PROGRAMMING CYCLE
STEP
1
Turn on the unit
2
Push TEST twice in sequence
Push TEST within 5" without releasing it until the
3
PRG LED is ON
Push TEST within 5" to select the desired FAN
4
time
Stop pressing TEST when the LED is on the Tx
5
corresponding to the desired time. Wait for all the
LEDs to go OFF.
6
End of programming
7
Turn the unit off and then back on
To choose the FAN time (point 4):
Press TEST once to select 5' (T1 ON)
Press TEST twice to select 10' (T2 ON)
Press TEST three times to select 20' (T3 ON)
Press TEST four times to select 40' (T4 ON)
If you don't need any FAN cycle, push TEST 5 times (all LEDs are OFF). The unit is programmed only for ALL1 and
ALL2 (alarm and trip)

ALARM RELAY TEST

STEP
1 Push TEST three times in sequence
Within 5" push TEST without releasing it until the
2 LEDs light up all together
After 5" the relay FAN lights up, followed by the
3
ALL1 and ALL2 relays
END OF THE TEST CYCLE
4
8
ACTION
ACTION
T119DIN
EFFECT
the green LED lights up
the red PRG LED flashes
the PRG LED is ON continuously
the red LED switches from
T1-T2-T3-T4
(FAN time 5'-10'-20'-40')
all the LEDs are switched OFF
EFFECT
the T1,2,3,4 LEDs light up in
sequence
LEDs T1,2,3,4 flash all together
the LEDs and relays of FAN 1-
ALL1-ALL2 are ON
all the red LEDs go OFF
