ACCESSORIES

The following objects are present inside the box:

Control unit

1 supply terminal 3 poles pitch 5

Code: 2PL0367 - Screws tightening torque 0.5Nm

1 PTC sensor terminal 4 poles pitch 5

Code: 2PL0369 - Screws tightening torque 0.5Nm

1 relay terminal 8 poles pitch 5

Code: 2PL0374 - Screws tightening torque 0.5Nm

ATTENTION: always install the device using the terminals included in the pack.

The use of terminals other than those included with the control unit might cause malfunctions.

T119DIN

1MN0030 REV. 0
