OPERATOR'S MANUAL
Compatibility
3
This engine will operate on any
traditional O-42 Gauge track system,
including M.T.H.'s RealTrax® or
ScaleTrax™ or traditional tubular track.
It is also compatible with most standard
AC transformers. (See page 46 & 47
for a complete list of compatible
transformers, power packs, and wiring
instructions.)
Freight Yard Sound
PLEASE READ BEFORE USE AND SAVE
