DATA ALLOCATION

'Begin' address is determined by the R7D's node address and the master setting.
• Example. R7D-DC8C
Output Data
None
I/O DATA DESCRIPTIONS
DISCRETE OUTPUT
15
0 : OFF
1 : ON
TRANSMISSION DATA DESCRIPTIONS
■ BASIC MODULE
Transmitted data (word) depends upon the modules types.
OUTPUT DATA*
MODEL
(R7D to Master)
R7D-DC8C
*1. Output Data means those sent to the master.
*2. Input Data means those received from the master.

WIRING INSTRUCTIONS

■ SCREW TERMINAL (Output)
Torque: 0.5 N·m
• SOLDERLESS TERMINAL
Refer to the drawing below for recommended ring tongue
terminal size. Spade tongue type is also applicable.
Applicable wire size: 0.25 to 1.65 mm
Recommended manufacturer: Japan Solderless Terminal
MFG. Co., Ltd, Nichifu Co., Ltd
3.3 (.13) max
■ EURO TYPE CONNECTOR TERMINAL (DeviceNet)
Applicable wire size: 0.2 – 2.5 mm
Stripped length: 7 mm
SEN TRONIC
Begin +0
0
Output 0
Output 1
Output 2
Output 3
Output 7
Not Used (Remains "0")
1 INPUT DATA* 2
(Master to R7D)
0 1
(AWG 22 to 16)
2
mm (inch)
2
056 222 38 18
AG
Input Data
8 points
:
mailbox@sentronic.com www.sentronic.com
R7D-DC8C
EM-7802-U Rev.2 P. 4 / 8
