Neotherm Futura W Pro SQ60524 Installer Manual

Package content
SQ60524(WB) Room Thermostat 1 x Installer Manual
Icons used in this manual:
Safety
Important info
Your benefit
Product Description
Thank you for purchasing the SQ60524(WB) Thermostat. This thermostat is a device that
lets you customise the heating and cooling of your home as needed. The SQ60524(WB) is
an electronic room temperature controller which offers key advantages over conventional
mechanical products. The controller is easy to operate using the conventional backlit
adjusting dial and offers you unique control convenience for heating applications of all types
thanks to the high quality device electronics.
We hope you enjoy our product.
Product Compliance
This product complies with the essential requirements and other relevant provisions of Directives
2014/30/ EU, 2014/35/EU and 2011/65/EU. The full text of the EU Declaration of Conformity is available
at the following internet address: www.saluslegal.com
Safety Information
Use in accordance to national and EU regulations. Use the device as intended, keeping it in dry condition.
Product for indoor use only. Installation must be carried out by a qualified person in accordance to
national and EU regulations. Disconnect your equipment before cleaning it with a dry cloth.
Warning:
Please always ensure the AC 24V mains power is switched off before installing or working on any
components.
User interface
Fixing Screws
1. Temperature scale
2. Dial button
3. LED
Temperature is set by turning the knob to wanted temperature: 5° - 35°C.
Installation
The ideal position to locate the thermostat is 1,5 m above floor level, far from heating
or cooling sources. The thermostat can't be exposed to sunlight or any extreme conditions,
for example draft. It should be mounted in a location where the thermostat is easily
accessible and away from direct sunlight.
1. Gently remove front housing and make the wiring connections
2. For wall mounting, mark the correct position on the wall and mount the rear case to
the wall.
1
2
3
Room Thermostat
Futura W Pro Analog 24V
INSTALLER MANUAL
