- Page 1 Quick Start Guide Tek-Flex 4100A Explosion Proof Guided Wave Radar Level Transmitter +1 847 857 6076 | +1 847 655 7428 796 Tek Drive, Crystal Lake, IL 60014 USA +1 847 655 6147 www.tek-trol.com...
-
Page 2: Before You Begin
2. Unpack One Tek-Flex 4100A Explosion Proof Guided Wave Radar Level Transmitter 3. Dimensional Drawing NEMA 4 (IP66) Enclosure... - Page 3 If this possibility occurs, secure a ring or mounting connection to the cable weight and to the vessel oor. Note: The Tek-Flex 4100A will come factory set for mounting to a metallic ange or tting unless otherwise instructed at time of order. Tek-Flex 4100A with 1½" NPT mounting in liquids, slurries or solids applications.
- Page 4 Flanged Tank Connection Nozzle Mount The transmitter can be mounted to a tank nozzle using the appropriate ange. Flange Mounting +1 847 857 6076 | +1 847 655 7428 796 Tek Drive, Crystal Lake, IL 60014 USA +1 847 655 6147 www.tek-trol.com...
- Page 5 Mounting on a Bypass/Bridle Tek-Flex 4100A transmitter can be successfully installed in a new or existing bypass pipe, bridle, or a side pipe as shown in the gure. This type of installation is often simple and allows the addition of radar level measurement to an otherwise busy installation.
- Page 6 (0.66 ft) diameter. Use metal shielding for the conduit connections. Mounting on a non-metallic vessel Mounting in Concrete Silos In case of concrete silos, the Tek-Flex 4100A should be mounted with a metal plate of minimum 8” (0.66 ft) diameter. Mounting in concrete silos +1 847 857 6076 | +1 847 655 7428 www.tek-trol.com...
-
Page 7: Power Supply
Technology Solutions 5. Power Supply COMMS Sinking 4-20mA from user device (max 750ohm) Sinking 4-20mA from Tek-Flex 4100A (max 250 ohm) DC In + Power Supply DC In - Communication 4-20 mA - Output (Sinking) 4-20 mA + 4-20 mA -... -
Page 8: Con Guration
• The Tek-Flex 4100A will take up to 30 seconds to warm up and stabilize upon initial start-up. It will then perform a scan to locate the level which will take approximately 1 sec or less. Once the load sequence is complete and the Tek-Flex 4100A has taken the rst measurement, the analog output indicates the material level (factory default) or distance measurement. - Page 9 Technology Solutions 796 Tek Drive Crystal Lake, IL 60014 Tel: +1 847 857 6076, +1 847 655 7428 Fax : +1 847 655 6147 Email: tektrol@tek-trol.com www.tek-trol.com Tek-Flex 4100A...
