- Page 1 Installation Instructions / Warranty Solaris E 04169XX0 Metro E 04195XX0 Allegro E 04182XX0...
- Page 2 04169XX0 04182XX0...
- Page 3 04195XX0 Technical Information / Données techniques / Datos tecnicos Recommended water Pression d’eau recommandée Presión recomendada 15 - 75 psi pressure en servicio Max. water pressure Pression d’eau maximum Presión en servicio max. 145 psi Recommended hot Température recommandée Temperatura recomen- 120�...
-
Page 4: Installation Considerations
Installation Considerations • For best results, Hansgrohe recommends that • This faucet requires ½" hot and cold supply this unit be installed by a licensed, profes- lines (not included). sional plumber. • Keep this booklet and the receipt (or other •... - Page 5 User Instructions / Instructions de service / Manejo closed open fermé ouvert cerrar abierto...
- Page 6 English Installation To insure correct operation of the faucet, install the hot valve on the left and the cold valve on the right. Remove the valve mounting nuts from the valves. Push the valves up into the holes. Install the mount- ing nuts on the valves.
- Page 7 Français Español Installation Instalación Installez la valve de l’eau chaude à gauche et Para que el grifo funcione correctamente, el sumin- celle de l’eau froide à droite. istro de agua caliente debe estar a la izquierda y el de agua fría a la derecha. Installez l’anneau de montage sur la valve.
- Page 8 English Screw the connecting hoses into the spout tee. Connect the hoses to the valve outlets. Use two wrenches. Do not allow the hoses twist or become loosened from the spout tee. 10 mm Install the supply lines (not included). Install the drain.
- Page 9 Français Español Installez les tuyaux dans le bec. Conecte las mangueras a las válvulas. Poussez l’extrémité du tuyau dans l’orifice de la Apriete las tuercas de la manguera con dos llaves, valve. como se muestra. Serrez le tuyau fermement l’écrou à l’aide de No permita las mangueras deux clés.
- Page 10 English Install the drain Remove the plunger assembly. Unscrew the drain outlet flange from the tee. Unscrew the tailpiece from the tee. Wrap the threads with Teflon tape and replace. Install the flexible sealing gasket on the flange. Sit it in the sink outlet. From below, install the black mack gasket, white friction ring, and retainer nut to the flange.
- Page 11 Français Español Installation de l’obturateur à Instale el tapón elevable clapet Retire el émbolo. Retirez le plongeur. Desenrosque la brida de salida del drenaje del tubo en “T”. Dévissez la collerette du raccord en T. Desenrosque la alcachofa del tubo en “T”. Dévissez la queue du raccord en T.
- Page 12 Replacement Parts / Pièces détachées / Repuestos 95244XX1 95247XX1 88744XX0 96657XX0 95248XX0 95245XX0 98127000 13961000 95246XX0 94008000 97357001 88509XX0 94009000 96321001 XX = colors / couleurs / acabados 00 = chrome 82 = brushed nickel...
- Page 13 Cleaning Recommendation for Hansgrohe Products Modern lavatory faucets, kitchen faucets, and showers consist of very different materials to comply with the needs of the market with regard to design and functionality. To avoid damage and returns, it is necessary to consider certain criteria when cleaning. Cleaning Materials for Faucets and Showers Acids are a necessary ingredient of cleaning materials for removing lime, however please pay attention to the following points when cleaning faucets and showers:...
- Page 14 Nettoyez vos produits de robinetterie et de douche aussi souvent que nécessaire. • Utilisez la quantité de produit nettoyant et respectez la durée recommandée par le fabricant. Ne laissez pas le produit sur les articles de robinetterie plus longtemps que nécessaire. •...
-
Page 15: Limited Lifetime Consumer Warranty
Limited Lifetime Consumer Warranty This product has been manufactured and tested to the highest quality standards by Hansgrohe, Inc. (“Hansgrohe”). This warranty is limited to Hansgrohe products which are purchased by a consumer in the United States after March 1, 1996, and installed in either the United States or Canada. - Page 16 Some States do not allow the exclusion or limitation of incidental or consequential damages, so the above limitation or exclusion may not apply to you. This warranty gives you specific legal rights, and you may have other rights which vary from State to State. You may be required by law to give us a reasonable opportunity to correct or cure any failure to comply before you can bring any action in court against us under the Magnuson-Moss Warranty Act.
