- Page 1 SSA-ISD Connect with Indication Instruction Manual Original Instructions 215320 Rev. B 1 February 2021 © Banner Engineering Corp. All rights reserved 215320...
-
Page 2: Table Of Contents
5 Product Support and Maintenance ..........................20 5.1 Maintenance and Service ................................20 5.2 Status Indicators ...................................20 5.3 EU Declaration of Conformity (DoC) .............................. 20 5.4 Information Available Using ISD ..............................21 5.5 Contact Us .....................................22 5.6 Banner Engineering Corp. Limited Warranty ..........................23... -
Page 3: Product Overview
The user is responsible for satisfying all local, state, and national laws, rules, codes, and regulations relating to the use of this product and its application. Banner Engineering Corp. has made every effort to provide complete application, installation, operation, and maintenance instructions. Please contact a Banner Applications Engineer with any questions regarding this product. -
Page 4: Installation Instructions
SSA-ISD Connect with Indication 2 Installation Instructions 2.1 Mechanical Installation Install the SSA-ISD Connect to allow access for functional checks, maintenance, and service or replacement. Do not install the SSA-ISD Connect in such a way to allow for intentional defeat. All mounting hardware is supplied by the user. -
Page 5: Protective (Safety) Stop Circuits
SSA-ISD Connect. An ISD compatible Banner Safety Controller, such as the SC10-2ro, provides a series connection of redundant contacts that form protective stop circuits for use in either single-channel or dual-channel control. -
Page 6: Fault Tolerant Output Feature
To ensure proper operation, the Banner device output parameters and machine input parameters must be considered when interfacing the Banner device OSSD outputs to machine inputs. Design the machine control circuitry so that the maximum load resistance value is not exceeded and the maximum specified OSSD Off-state voltage does not result in an On condition. -
Page 7: Wire The Ssa-Isd Connect In A Chain Of Isd E-Stops
CH2a - Pin 4 - Black CH2b - Pin 5 - Gray MQDMC-5xx SSA-ISD-TCA 2.5.1 Wire the SSA-ISD Connect in a Chain of ISD E-Stops When connecting emergency stop units in series, simplify the wiring by using special t-adapters, low cost unshielded four- wire double-ended cables, and the SSA-ISD Connect with Indication. -
Page 8: Wire The Ssa-Isd Connect In A Chain Of Isd Interlocks
6. Wire the wired end of the 4-pin M12 cable (from step 1) directly to a Safety Monitoring Device, such as an ISD- enabled Banner Safety Controller model SC10-2roe. You may also wire the 4-pin M12 cable to an In-Series Diagnostic (ISD) module then to the Safety Monitoring device. -
Page 9: Wiring Additional Power Supplies
6. Wire the wired end of the 4-pin M12 cable (from step 1) directly to a Safety Monitoring Device, such as an ISD- enabled Banner Safety Controller model SC10-2roe. You may also wire the 4-pin M12 cable to an In-Series Diagnostic (ISD) module then to the Safety Monitoring device. - Page 10 Note: Option 1 can only be used if the chain contains an SI-RFA-TS connector (the SI-RFA-TK cannot be connected to an SSA-ISD-TCA). Figure 7. Option 2: Replace the terminator with a power supply. The OSSD1 and OSSD2 wires at power supply #2 must be connected to +24 V DC. If available, set the power supplies for parallel output.
-
Page 11: Checkout
SSA-ISD Connect with Indication Figure 8. Maximum total cable length for a single power supply Max. Total Series Cable (m) Single Power Supply SI-RF E-Stops Number of ISD Devices The ISD Connect has a similar current demand to the SI-RFD sensors. However, when used with a number of lighted ISD E- Stops, the current draw of the E-stops governs the cable lengths and when more power is needed. -
Page 12: In-Series Diagnostic (Isd) Information
To interpret this information, Banner diagnostic modules are available, including the SI-RF-DM1 and -DM2 Diagnostic Modules and the SC10-2roe Safety Controller. Refer to the instruction manuals for detailed information on the diagnostic devices. -
Page 13: Specifications
SSA-ISD Connect with Indication 3 Specifications Important: Interface the SSA-ISD Connect with Indication only to a SELV (Safety Extra-Low Voltage) for circuits without earth ground or a PELV (Protected Extra-Low Voltage) for circuits with earth ground power supply according to EN/IEC 60950. Rated Supply Voltage (Ue) OSSD Outputs 24 V DC +15%, -20% (SELV/PELV power supply) -
Page 14: Dimensions
SSA-ISD Connect with Indication 3.1 Dimensions All measurements are listed in millimeters, unless noted otherwise. www.bannerengineering.com - Tel: + 1 888 373 6767... -
Page 15: Accessories
SSA-ISD Connect with Indication 4 Accessories 4.1 Cordsets 4-Pin Threaded M12/Euro-Style Cordsets—Single Ended Model Length Style Dimensions Pinout (Female) MQDC-406 2 m (6.56 ft) 44 Typ. MQDC-415 5 m (16.4 ft) Straight MQDC-430 9 m (29.5 ft) M12 x 1 ø... - Page 16 SSA-ISD Connect with Indication 4-Pin Threaded Male M12/Euro-Style Cordsets—Single Ended Model Length Style Dimensions Pinout (Male) MQDMC-406RA 1.83 m (6 ft) 31.8 mm (1.25") MQDMC-415RA 4.57 m (15 ft) Right-angle 31 mm (1.22") MQDMC-430RA 9.14 m (30 ft) M12X1 Ø13.5 mm (0.53") 5-Pin Threaded Male M12/Euro-Style Cordsets—Single Ended Model...
- Page 17 SSA-ISD Connect with Indication 4-Pin Threaded M12/Euro-Style Cordsets—Double Ended Model Length Style Dimensions Pinout MQDEC-403RS 0.91 m (2.99 ft) 32 Typ. [1.26"] MQDEC-406RS 1.83 m (6 ft) 30 Typ. MQDEC-412RS 3.66 m (12 ft) [1.18"] Male Right-Angle/ MQDEC-420RS 6.10 m (20 ft) M12 x 1 Female Straight ø...
-
Page 18: Adapters And Other Accessories
4.4 ISD Connect Compatible Devices The following tables list devices that can be directly connected to the ISD Connect via Quick Disconnect cables. The following E-stops with Quick Disconnect connectors can be directly connected to the SSA-ISD-TCA using a MQDEC-5xxSS or DEE2R-5xxD cable. - Page 19 SSA-ISD Connect with Indication Model Push Button Housing E-Stop Contacts Connections SSA-EB1PL2-02ECQ5A Illuminated 40 mm 30 mm mount 2 NC CH1 = pin 1 & 2, CH2 = pin 4 & 5 The following Safety Limit and Hinge Switches with Quick Disconnect connectors can be directly connected to the SSA- ISA-TCA with splitter cable CSE5A-M1251M1251 and MQDEC-5xxSS or DEE2R-5xxD if needed.
-
Page 20: Product Support And Maintenance
5.3 EU Declaration of Conformity (DoC) Banner Engineering Corp. herewith declares that these products are in conformity with the provisions of the listed directives and all essential health and safety requirements have been met. For the complete DoC, please go to www.bannerengineering.com. -
Page 21: Information Available Using Isd
Directive SSA-ISD Connect with Indication Machinery Directive 2006/42/EC Representative in EU: Peter Mertens, Managing Director, Banner Engineering BV. Address: Park Lane, Culliganlaan 2F, bus 3,1831 Diegem, Belgium. Information Available Using ISD Obtain the following information from the ISD chain and a diagnostic unit or an ISD-enabled Safety Controller. -
Page 22: Contact Us
ISD information stops. After a number of seconds (approximately 5 seconds) the information resumes minus the devices that have been separated from the chain. 5.5 Contact Us Banner Engineering Corp. headquarters is located at: 9714 Tenth Avenue North Minneapolis, MN 55441, USA Phone: + 1 888 373 6767 For worldwide locations and local representatives, visit www.bannerengineering.com. -
Page 23: Banner Engineering Corp. Limited Warranty
