CM4825-C
ASSEMBLY RATING
Tools Required for Assembly:
The Assembly Rating is a 5-point system that
Allen Wrench
shows the degree of effort needed in
(Included)
assembling a specific product (with 1 being
easy and 5 being difficult). For some
Hex Wrench
products, two persons are recommended.
(Included)
DIFFICULT
EASY
2 PERSONS RECOMMENDED
Page 1 of 5
Rev.14-12-01
Advertisement
Table of Contents
Related Manuals for Furniture of America Lodia CM4825-C
Summary of Contents for Furniture of America Lodia CM4825-C
- Page 1 Assembly Instructions CM4825-C ASSEMBLY RATING Tools Required for Assembly: The Assembly Rating is a 5-point system that Allen Wrench shows the degree of effort needed in (Included) assembling a specific product (with 1 being easy and 5 being difficult). For some Hex Wrench products, two persons are recommended.
- Page 2 Page 2 of 5...
- Page 3 Before you begin, please read Page 2 of “Assembly and Care Advice”. And remember, do not tighten until each step is completed or instructed. Hardware List (Continued) Parts List #1 x 1 pc #D x 1 pc Glass Top Allen Wrench #E x 6 pcs #2 x 1 pc Leveler...
- Page 4 Carefully place the glass top (#1) facing down on a protected surface. Insert the 2 threaded studs (#B) into the pre-drilled holes on the center of the glass top (#1). Place the pedestal (#2) over the 2 threaded studs (#B). Then place 2 large flat washers (#H) over the 2 threaded studs (#B).
- Page 5 Insert the 2 covers (#I) over the 2 hex nuts (#G) secured to the pedestal (#2). #I x 2 pcs Carefully place the table in its upright position. Make sure the table is rested on a flat surface and does not feel loose or wobbly.
