iLive ISB202 User Manual

Bluetooth Speaker
User's Guide for Model ISB202 v2892-01
Features
• Bluetooth wireless 5.0: range 59 ft.
• Micro SD card port
• Digital volume control
• Voice prompts
• Built-in rechargeable battery: approximately 7 hrs of
playtime at 50% volume
• Micro-USB port for battery recharge
Includes
• User's Guide
• Micro-USB to USB charging cable
Controls
1
2
1. Mode: Press to change source modes to Bluetooth, Aux,
USB or Micro SD/TF. Press and hold to turn LED lights
ON/OFF.
2. Volume-/Previous: Press to decrease volume level. Press
and hold to play previous track. In FM mode, press to
change stations.
3. Play/Pair: While playing music, press to play/pause
tracks. Press and hold for 3 seconds to pair Bluetooth
device manually.
4. Volume+/Next: Press to increase volume level. Press and
hold to play the next track. In FM mode, press to change
stations.
Note: To turn voice prompts ON/OFF, press and hold both the
Volume+ / Volume- buttons for 3 seconds.
Inputs
Indicator LED
Aux In Power Switch
Microphone
Input
DC Power Input
Charging the Battery
To charge the internal battery, plug the USB charging cable
into the DC Power Input on the speaker and a powered on
computer or USB power adapter (not included) and standard
power outlet. Charging time is approximately 4 hours.
When the battery is low a voice will announce "Low Battery, "
then the unit will automatically power OFF.
While the unit is charging the LED Indicator will display a
solid red light. When the battery is fully charged the light will
turn off.
3
4
Pairing & Playing Bluetooth Audio
USB Port
TF/Micro SD
1. When first powered on, the speaker defaults to Bluetooth
Mode and is ready to pair automatically. When pairing,
remain within 3 feet of the Bluetooth device.
2. Using the controls on your Bluetooth device, select
ISB202 in the Bluetooth Settings to pair. If need be, refer
to the user's manual for your specific device for more
information.
3. When successfully paired, a voice will announce,
"Bluetooth is connected. " The LED Indicator will display
a solid blue light. Your Bluetooth device will now be
heard through the speaker.
4. Use the controls on the connected Bluetooth device to
select and play audio. Use the speaker controls or the
connected Bluetooth device to play, pause, and adjust
the volume level.
5. After initial pairing, the speaker will automatically
connect to the last Bluetooth device used whenever it is
in Bluetooth Mode. Note: If your device should become
unpaired or you find it is unable to connect, press and
hold the Play/Pair button to enter to Pairing Mode. A
voice will announce, "Bluetooth is connecting, " and you
can connect to the speaker manually.
