EBERBACH E6140.00 Manual

Orbital shaker variable speed with timer and tachometer 30-320 rpm, 230/115 v, 50/60 hz
Hide thumbs

Advertisement

Quick Links

Download this manual
505 S Maple Road – Ann Arbor, MI 48103 – USA
TEL (800) 422-2558 – FAX (734) 665-9099
Eberbachlabtools.
.
com
www
E6140.00 Orbital Shaker
Variable Speed with Timer and Tachometer
30-320 rpm, 230/115 V, 50/60 Hz

Advertisement

loading
Need help?

Need help?

Do you have a question about the E6140.00 and is the answer not in the manual?

Questions and answers

Related Manuals for EBERBACH E6140.00

Summary of Contents for EBERBACH E6140.00

  • Page 1 505 S Maple Road – Ann Arbor, MI 48103 – USA TEL (800) 422-2558 – FAX (734) 665-9099 Eberbachlabtools. E6140.00 Orbital Shaker Variable Speed with Timer and Tachometer 30-320 rpm, 230/115 V, 50/60 Hz...

  • Page 2: General Information

    Eberbach Corporation technical service. Weight/Speed Considerations: Maximum load and maximum speed specifications for Eberbach shakers are established both as a guide to ensure long operational life of the units and as safety parameters for the operator. When shaking heavy loads at higher speeds always monitor the progress of the shaking action for a few minutes.
  • Page 3 1) Power Switch 2) Liquid Crystal Display (LCD) 3) Directional Pad (D-Pad) 4) Enter Button 5) Cursor Operation: Press the Power Switch down into the ON position. The LCD should light up and show the main menu. There are three different run modes to choose from.
  • Page 4 Run Mode: The shaker will begin the run mode at its lowest speed. The speed shown in parenthesis (xxxx) is the set speed controlled by the user. The speed listed to the right is the tachometer read out or the actual speed of the shaker in real time.
  • Page 5 Timed Run Mode: The timed run mode features a count down timer that automatically shuts the shaker off when the time runs out. When selected the user will be taken to the Timed Run Setup Menu and will need to input the run time in hours, minutes, seconds and select the speed for the run.
  • Page 6 After selecting START the shaker will begin at the selected speed and the timer will begin counting down. The speed can be adjusted in real time using the up/down arrows on the D-PAD. The speed shown in parenthesis is the target speed controlled by the user and the speed listed to the right is the actual speed as read by the tachometer.
  • Page 7 Speed Run Mode: The speed run allows the user to program in a set run speed. Once engaged the timer will begin counting all the way up to 999 hours before the timer overflows back to zero. Select the speed run mode from the main menu and press the Enter Button.
  • Page 8 Restoring the Factory Settings: During the course of operation the machine may need to be reset to its factory settings. To do so the user must press and hold the green Enter Button. Next the user must turn the Power Switch on, while continuing to hold the Enter Button.
  • Page 9 The Cursor should be next to the line item “Model : xxxx” use the up/down arrow buttons, on the D-PAD, to select E6140. The models are listed numerically with the smallest numbers at the bottom and the largest numbers at the top. If the line reads “Model: Empty” then press and hold the down arrow button to get back into the model numbers.
  • Page 10 Note: Do not rotate machine by hand as doing so may corrupt the digital memory and require a factory reset. If you have any doubts or inquiries concerning operation contact your supplier or Eberbach Corporation technical service. LOADING: It is impossible to outline the exact limitations for loading a shaker, as resulting shaking action is dependent upon several factors.

  • Page 11: Belt Inspection

    • At higher speed use less weight on platform. • When using a tiered platform (one platform above the other), place equal load on each or, if possible, place heavier mass on lower platform and lighter on the top. If shaking action imparts a “whip” to the upper platform, then either the speed is too high or the load is too heavy on that platform.
  • Page 12 REPLACEMENT PARTS LIST FOR 6140.00 Part No DESCRIPTION QTY. 4116 BEARING NTN 1.85" DIA 4303.5 TIMING BELT 4436 30 L PULLEY X 1/2 BORE, 30 TEETH, WITH SETSCREW 5528 3.75" SUCTION CUP W/ 5/16-18 THREADED POST 6009 175W POWER SUPPLY 24V/12V RAILS 6027.510A 5V VOLTAGE REGULATOR 6063.1...
  • Page 13 SPINDLE EP6140.262 ECCENTRIC PIN EP6140.265 BEARING RETAINER EP6140.511A FRONT PANEL ASSEMBLY EP6140.512A BACK PANEL ASSEMBLY EP6140.515A BASE ASSEMBLY EP6140.650A WIRING HARNESS EP6145.208 ECCENTRIC BLOCK Contact your supplier or Eberbach Corporation technical support with any inquiries concerning replacement parts and installation.
