- Page 1 5900 Schooner Street – Belleville, MI 48111 – USA TEL (800) 422-2558 – FAX (734) 665-9099 Eberbachlabtools. EL680.Q QUENCHERS Hand Motion Shaker Variable Speed with Timer and Tachometer 100-600 +/-2 opm, 115 V, 50/60 Hz...
- Page 2 USE AND CARE FOR CATALOG NUMBER: EL680.Q Digital Variable Speed Reciprocating Shaker - 115V - 50/60 Hz CAUTION! UNPLUG THE POWER CORD BEFORE DOING ANY MAINTENANCE ON THIS MACHINE. FAILURE TO DO SO MAY CAUSE INJURY !!THE USER OF THIS DEVICE IS RESPONSIBLE FOR OBTAINING THE...
-
Page 3: General Information
USE AND CARE FOR CATALOG NUMBER: EL680.Q Wrist Action Shaker Variable Speed with Timer and Tachometer 100-600 +/-2 opm, 115V- 50/60 Hz GENERAL INFORMATION Handle this unit with care. Unpack and check that the contents coincide with the packing-list. If any part is damaged or missing, please advise the distributor immediately. -
Page 4: Equipment Description
EQUIPMENT DESCRIPTION Wrist Action Shaker: Electronic regulation between 100 and 600 oscillations per minute. Oscillation amplitude is 9mm. Easily detachable arms equipped with 8 clamps for attaching and processing up to 8 samples at one time. TECHNICAL FEATURES Voltage supply 115V, 50/60 Hz Height 18 in Length... - Page 6 1) Power Switch 2) Liquid Crystal Display (LCD) 3) Directional Pad (D-Pad) 4) Enter Button 5) Cursor Operation: Press the Power Switch down into the ON position. The LCD should light up and show the main menu. There are three different run modes to choose from.
- Page 7 Run Mode: The shaker will begin the run mode at its lowest speed. The speed shown in parenthesis (xxxx) is the set speed controlled by the user. The speed listed to the right is the tachometer read out or the actual speed of the shaker in real time. The speed can be increased/decreased by pressing and holding the up/down arrows on the D-PAD.
- Page 8 Timed Run Mode: The timed run mode features a count down timer that automatically shuts the shaker off when the time runs out. When selected the user will be taken to the Timed Run Setup Menu and will need to input the run time in hours, minutes, seconds and select the speed for the run.
- Page 9 After selecting START the shaker will begin at the selected speed and the timer will begin counting down. The speed can be adjusted in real time using the up/down arrows on the D-PAD. The speed shown in parenthesis is the target speed controlled by the user and the speed listed to the right is the actual speed as read by the tachometer.
- Page 10 Speed Run Mode: The speed run allows the user to program in a set run speed. Once engaged the timer will begin counting all the way up to 999 hours before the timer overflows back to zero. Select the speed run mode from the main menu and press the Enter Button.
- Page 11 Restoring the Factory Settings: During the course of operation the machine may need to be reset to its factory settings. To do so the user must press and hold the green Enter Button. Next the user must turn the Power Switch on, while continuing to hold the Enter Button.
- Page 12 The Cursor should be next to the line item “Model : xxxx” use the up/down arrow buttons, on the D-PAD, to select EL680Q. The models are listed numerically with the smallest numbers at the bottom and the largest numbers at the top. If the line reads “Model: Empty” then press and hold the down arrow button to get back into the model numbers.
- Page 13 Note: Use slowest speed necessary to produce required shaking action. Note: Do not rotate machine by hand as doing so may corrupt the digital memory and require a factory reset. If you have any doubts or inquiries concerning operation contact your supplier or Eberbach Corporation technical service.
-
Page 14: Maintenance
The problem is generally in extreme wear of the bearings or an object obstructing the shaking action. NOTE: If replacement fuse blows almost immediately, repairs may be necessary. If you have any doubts or inquiries concerning operation contact your supplier or Eberbach Corporation technical service. - Page 15 Be careful not to lose the inside spring when unscrewing brush holders. 3. Inspect brushes and clean or replace as necessary. Replace brushes if worn to less than 1/8”. If you have any doubts or inquiries concerning operation contact your supplier or Eberbach Corporation technical service.
- Page 16 ELP680.Q REPLACEMENT PARTS LIST PartNo DESCRIPTION QTY. 4112 BEARING 4113 BEARING 4259 16" TIMING BELT 4400.3 4MM X 20MM KEY 4508 TIMING PULLEY, 22 TEETH 5339.5 INTRENAL SNAP RING FOR 1-3/8" BORE 5528 3.75" SUCTION CUP W/ 5/16-18 THREADED POST 5535.5 RUBBER GROMMET 5631...
- Page 17 #8-32 S/S MACHINE SCREW NUT 9261 1/4"-20 GRADE 5 EXTRA-WIDE HEX NUT 9283 3/8"-24 GRADE 5 HEX NUT 9435 #12 SAE WASHER 9950 BLUE LOCTITE 242 EL680.Q.009 MOTOR CONTROLLER SPLASHGUARD ELP680.HD.211 RIGHT SIDE COLUMN ELP680.HD.212 PULLEY BLOCK ELP680.HD.217 LEFT SIDE COLUMNS ELP680.HD.315 CROSS STRAP ELP680.HD.525A...
- Page 18 TACH BRACKET ELP680.Q.SS.507A REAR PANEL ASSEMBLY ELP680.SS.220 BASE PLATE ELP680.SS.223 SIDE PANEL ELP680.SS.508A CASE ASSEMBLY If you have any questions or inquiries concerning installation or ordering of replacement parts please contact your supplier or Eberbach Corporation Technical Service @ 1-800-422-2558.
