- Page 1 5900 Schooner Street – Belleville, MI 48111 – USA TEL (800) 422-2558 – FAX (734) 665-9099 Eberbachlabtools. E6155.00 Orbital Shaker Variable Speed with Timer and Tachometer 30-300 rpm, 115 V, 50/60 Hz...
-
Page 2: General Information
USE AND CARE FOR CATALOG NUMBER: - E6155.00 Orbital Shaker Power Unit Variable Speed 30-300 rpm with Timer and Tachometer 115V 50/60Hz GENERAL INFORMATION o Handle this unit with care. Unpack and check that the contents coincide with the packing-list. If any part is damaged or missing, please advise the distributor immediately. -
Page 3: Operation
OPERATION The Eberbach orbital shaker catalog # E6155.00 features: o An Oriental 400W BLDC Motor Drive for long life and low maintenance. o A digital tachometer and timer for simple and accurate use. o Base designed to be moved with a narrow fork (21”) forklift or pallet jack. - Page 4 See Graph Below For Maximum Load/Speed Recommendations Based on Orbit Diameter Contact Eberbach Corporation Technical Support for other stroke setting weight limits.
- Page 5 1) Power Switch 2) Liquid Crystal Display (LCD) 3) Directional Pad (D-Pad) 4) Enter Button 5) Cursor Operation: Press the Power Switch down into the ON position. The LCD should light up and show the main menu. There are three different run modes to choose from.
- Page 6 Run Mode: The shaker will begin the run mode at its lowest speed. The speed shown in parenthesis (xxxx) is the set speed controlled by the user. The speed listed to the right is the tachometer read out or the actual speed of the shaker in real time.
- Page 7 Timed Run Mode: The timed run mode features a count down timer that automatically shuts the shaker off when the time runs out. When selected the user will be taken to the Timed Run Setup Menu and will need to input the run time in hours, minutes, seconds and select the speed for the run.
- Page 8 After selecting START the shaker will begin at the selected speed and the timer will begin counting down. The speed can be adjusted in real time using the up/down arrows on the D-PAD. The speed shown in parenthesis is the target speed controlled by the user and the speed listed to the right is the actual speed as read by the tachometer.
- Page 9 Speed Run Mode: The speed run allows the user to program in a set run speed. Once engaged the timer will begin counting all the way up to 999 hours before the timer overflows back to zero. Select the speed run mode from the main menu and press the Enter Button.
- Page 10 Note: Reciprocating shakers will display OSC (oscillations) instead of RPM (revolutions per minute). Note: Use slowest speed necessary to produce required shaking action. If you have any doubts or inquiries concerning operation contact your supplier or Eberbach Corporation technical service. LOADING:...
-
Page 11: Belt Inspection
It is impossible to outline the exact limitations for loading a shaker, as resulting shaking action is dependent upon several factors. Principal among these is the size and shape of the containers, speed, orbit radius, and the amount and type of material being shaken. - Page 12 REPLACEMENT PARTS LIST FOR E6155.00 PartNo DESCRIPTION QTY. 4220 BELT-A32 4400.6 1/4" X 1.0" KEY 4482.6 AK64X1" KEYED 6010.7 POWER SUPPLY, 5V 30W 6063 CABLE TIE, LOW PROFILE MOUNT 6063.2 ZIP TIE 6102 OVERLAY 6129 FUSE, 5AMP TIME DELAY 6131.1...
- Page 13 8509 1/4"-20 X 5/8" HEX HEAD SCREW 8533.6 1/4-20" X 2-3/4" HEX HEAD SCREW 8576 #4-40 X 3/8" S/S SOCKET HD. SCREW 8641 1/2"-13 X 2-1/4" SOCKET HD. SCREW 9206 #6-32 S/S NYLON LOCK NUT 9235 #8-32 S/S MACHINE SCREW NUT 9437 1/4 WASHER ZINC PLATED 9487...
