HERRINGBONE DINING CHAIR
ASSEMBLY INSTRUCTIONS
A. CHAIR BACK ( 1 PC)
PARTS PACKING CONFIGURATIONS
B. CHAIR SEAT ( 1 PC)
C. FRONT LEG ( 2 PCS)
HARDWARE LIST:
Description
No.
1
ALLEN BOLT (M6X40)
2
ALLEN BOLT (M6X30)
3
HEX NUT (M8)
4
FLAT WASHER (M6)
5
SPRING WASHER (M6)
6
FLAT WASHER (M8)
7
SPRING WASHER (M8)
8
ALLEN KEY
9
SPANNER
MODUS
F U R N I T U R E
Quantity
3 PCS
4 PCS
4 PCS
7 PCS
7 PCS
4 PCS
4 PCS
1 PC
1 PC
Advertisement
Table of Contents
Related Manuals for Modus Furniture HERRINGBONE 5QS363B
Summary of Contents for Modus Furniture HERRINGBONE 5QS363B
- Page 1 HERRINGBONE DINING CHAIR MODUS ASSEMBLY INSTRUCTIONS F U R N I T U R E PARTS PACKING CONFIGURATIONS A. CHAIR BACK ( 1 PC) B. CHAIR SEAT ( 1 PC) C. FRONT LEG ( 2 PCS) HARDWARE LIST: Description Quantity Photo ALLEN BOLT (M6X40) 3 PCS...
- Page 2 HERRINGBONE DINING CHAIR MODUS ASSEMBLY INSTRUCTIONS F U R N I T U R E STEP 1: STEP 2:...
- Page 3 HERRINGBONE DINING CHAIR MODUS ASSEMBLY INSTRUCTIONS F U R N I T U R E HERRINGBONE DINING CHAIR FULLY ASSEMBLED : IF YOUR CHAIR IS NOT LEVEL AFTER ASSEMBLY, MOVE CHAIR TO A FLAT, LEVEL AREA. LOOSEN, BUT DO NOT COMPLETELY UNDO, ALL BOLTS. ONCE CHAIR ASSEMBLY IS LOOSE, LEVEL CHAIR ON FLAT SURFACE.
