- Page 1 APUS Extruder Instruction Product Please read and keep this manual carefully before using our products properly...
-
Page 2: Product Appearance
Product Appearance Thank you for buying Phaetus' APUS Extruder www.phaetus.com... -
Page 3: Product Features
Product Features Easy Optimized RNC maintenance Dual Drive Gears 155g lightweight 6.3 : 1 Gear ratio all metal design Specifications Product Name: APUS Extruder Product Size: 67mm*64mm*42mm Product Color: Blue Product Net Weight: 155g www.phaetus.com... - Page 4 PLA, ABS, PETG TPU, PP, PC, PA PEEK and PEI as well as typical composite fibre filaments such as PLA-CF, ABS-CF, PETG-CF and PA-CF/GF. Composite filaments such as steel, wood, boron carbide, tungsten and fluorescence materials can be processed by the extruder. www.phaetus.com...
-
Page 5: Parts And Accessories
Parts & Accessories Motor Extension Cable -5cm (Molex Micro Fit 3.0-DuPont TJC8-4) Motor Extension Cable -5cm (Molex Micro Fit 3.0-JSTXHP-4) H2.0 Hex Key H2.5 Hex Key Button Head Screw M3X12 Cap Head Screw M3x12 www.phaetus.com... -
Page 6: Product Material
Product Material Aluminium Aluminium filament guide Idler arm Aluminium gear Aluminum frame RNC Hardened Steel Dual Drive gear www.phaetus.com... - Page 7 ・Easy loading and unloading of filament using the manual wheel. ・Gravity align to the fix mount ensure the stability of high speed printing. ・Very easy to disassemble during maintenance due to the “3-Screws-System” www.phaetus.com...
- Page 8 Copyright Phaetus © 2022 Phaetus. All rights reserved. phaetus.com Phaetus, the Phaetus logo, are trademarks of Phaetus, registered in China and other countries and regions. Other company and product names mentioned herein may be trademarks of their respective companies. Every effort has been made to ensure that the information in this manual is accurate.
-
Page 10: Assembly Steps
1. Use 2 M3*8 screws to fix the filament inlet on the front plate. Pay attention to the direction of the filament inlet that it should face outward. 2. Use 2 M3*8 screws, and secure the extruder connection on the front plate. www.phaetus.com... - Page 11 3. Press two F683ZZ bearings into the IdIer Hob Gear. 4. Use the plug screw 3*8*M2.5, lock the IdIer Hob Gear to the IdIer Arm. www.phaetus.com...
- Page 12 5. Use M3*8 screws to fix the IdIer Arm on the front plate. 6. Use 4 M3*8 screws, secure the back plate to the components. www.phaetus.com...
- Page 13 7. Place 2 M3*12 screws into the hole of the extruder connector. 8. Use 2 M3*6 screws, fix the stepper motor to the back plate. www.phaetus.com...
- Page 14 10. Install the mounted gear shaft into the back plate, and note that the flange of the bearing is close to the side back plate. www.phaetus.com...
- Page 15 11. Install the bearing MF126ZZ on the front plate, and note that the flange of the bearing is close to the front plate. 12. Put 4 M3*12 screws into the hot end connector. www.phaetus.com...
- Page 16 13. Use 2 M3*25 screws. Start from the front plate and secure the hot end connector. The screws lead to the back plate. 14. Install the adjustment screw. Pass them through the spring and idler arm, and then fix them on the filament inlet. www.phaetus.com...
- Page 17 15. Install the manual wheel on the gear shaft, and then thread the M3*8 screws through the elastic pad and the flat pad in turn and fix them on the gear shaft. 16. Attach the cap to the manual wheel. www.phaetus.com...
- Page 18 17. Install the pneumatic interface. 18. The exploded view of the entire product is shown below. www.phaetus.com...
