These instructions accompanying the product are the original instructions. This document is part of the product,
keep it for the life of the product passing it on to any subsequent holder of the product. Read all these
instructions before assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been
designed, and contains all the necessary information to ensure its correct and safe use. By following all the
general safety instructions contained in this manual, it will ensure both product and operator safety, together
with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper
Tools policy of continuous improvement determines the right to make modifications without prior warning.
Advertisement
Table of Contents
Related Manuals for Draper FCR-701
Summary of Contents for Draper FCR-701
- Page 1 AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.
-
Page 2: Title Page 1.1 Introduction
Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Draper Tools Limited. In all cases this copyright notice must remain intact. -
Page 3: Table Of Contents
CONTENTS 1. TITLE PAGE 1.1 INTRODUCTION......................2 1.2 REVISION HISTORY ....................2 1.3 UNDERSTANDING THIS MANUAL ................2 1.4 COPYRIGHT NOTICE ....................2 2. CONTENTS 2.1 CONTENTS ........................3 3. GUARANTEE 3.1 GUARANTEE ....................... 4 4. INTRODUCTION 4.1 SCOPE......................... 5 4.2 SPECIFICATION ...................... -
Page 4: Guarantee
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the guarantee period. -
Page 5: Introduction
0.15A Multilingual support ..............English, French, Spanish, German. Weight ..........................0.298kg Note: Draper Tools accepts no responsibility for any accident or injury arising from servicing the vehicles system. When interpreting results from the vehicle, always follow the manufacturer’s recommendation for repair. -
Page 6: Health And Safety Information
HEALTH AND SAFETY INFORMATION 5.1 GENERAL SAFETY INSTRUCTIONS For your own safety and the safety of others, and to prevent damage to the equipment and vehicles, read the full online manual at drapertools.com thoroughly before operating your scanner. The safety messages presented below and throughout this user’s manual are reminders to the operator to exercise extreme care when using this device. -
Page 7: Technical Description
TECHNICAL DESCRIPTION 6.1 IDENTIFICATION Scart connection. (6) Micro SD card slot. (2) LCD screen. (7) USB Port. (3) Erase button. (8) Selection and advance button. (4) DTC (Digital Trouble Codes) button. (9) OK button. (5) Back to previous screen button. (10) Help button. -
Page 8: Unpacking And Checking
Lay the contents out and check them against the parts shown below. If any part is damaged or missing; please contact the Draper Helpline (the telephone number appears on the Title page) and do not attempt to use the machine. -
Page 9: Preparation & Connections
PREPARATION & CONNECTIONS Note: To make sure the tool is running the latest available software. it is advisable to check for updates on a frequent basis. Refer to "Register & Update" for details. 8.1 PREPARATION • Turn the vehicle ignition on. •... -
Page 10: Register & Update
REGISTER & UPDATE NOTE: The TF CARD should NOT be reformatted at any point. This will remove all information including product serial number and register code. If this is to happen: 1. Remove TR CARD. 2. Power unit on, the serial number and register code will display for a few seconds, capture this information to restore system. - Page 11 REGISTER & UPDATE 4. The Register Code can be found in your tool. Connect Help one end of the USB cable to your tool, and the other end on the computer. DLC Location Information 5. After the tool has powered up and entered the main DTC Library menu screen, move the highlight bar on the "Help"...
-
Page 12: Method 2: Via Usb Cable
REGISTER & UPDATE 9.3 METHOD 2: VIA USB CABLE Help Note: Make sure the computer has an Internet connection. 1. Connect one end of the USB cable to the USB port of computer, and the other end to the tool. 2. -
Page 13: Main Menu Screen
10. MAIN MENU SCREEN 10.1 FUNCTIONS Once the tool is powered, it will enters the main menu screen, it mainly includes the following functions: • Diagnose: It mainly consists of OBD/EOBD diagnosing and Reset/System Scanning (varies with product models). • Review: To review the recorded DTC, datastream etc. •... -
Page 14: Disposal
13. DISPOSAL 13.1 DISPOSAL – At the end of the machine’s working life, or when it can no longer be repaired, ensure that it is disposed of according to national regulations. – Contact your local authority for details of collection schemes in your area. In all circumstances: •... - Page 15 NOTES - 15 -...
- Page 16 ©Published by Draper Tools Limited. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
