BATTERY
DIAGNOSTIC
TOOL
81164
These instructions accompanying the product are the original instructions. This document is part of the product,
keep it for the life of the product passing it on to any subsequent holder of the product. Read all these
instructions before assembling, operating or maintaining this product.
This manual has been compiled by Draper Tools describing the purpose for which the product has been
designed, and contains all the necessary information to ensure its correct and safe use. By following all the
general safety instructions contained in this manual, it will ensure both product and operator safety, together
with longer life of the product itself.
AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the
product.
Whilst every effort has been made to ensure the accuracy of information contained in this manual, the Draper
Tools policy of continuous improvement determines the right to make modifications without prior warning.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 81164 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Draper 81164

Summary of Contents for Draper 81164

  • Page 1 AlI photographs and drawings in this manual are supplied by Draper Tools to help illustrate the operation of the product.

  • Page 2: Introduction

    Commercial copying, redistribution, hiring or lending is prohibited. No part of this publication may be stored in a retrieval system or transmitted in any other form or means without written permission from Draper Tools Limited. In all cases this copyright notice must remain intact.

  • Page 3: Table Of Contents

    CONTENTS 1. TITLE PAGE 1.1 INTRODUCTION......................2 1.2 REVISION HISTORY ....................2 1.3 UNDERSTANDING THIS MANUAL ................2 1.4 COPYRIGHT NOTICE ....................2 2. CONTENTS 2.1 CONTENTS ........................3 3. GUARANTEE 3.1 GUARANTEE ....................... 4 4. INTRODUCTION 4.1 SCOPE......................... 5 4.2 SPECIFICATION ......................

  • Page 4: Guarantee

    This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised. Your Draper guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your proof of purchase within the guarantee period.

  • Page 5: Introduction

    This battery diagnostic tool allows you to easily, quickly and accurately measure the actual cold cranking amps capability of the vehicle’s starting battery, health state of the battery and the vehicle’s starting system and charging system. 4.2 SPECIFICATION Stock No........................... 81164 Part No..........................BDT/M Measure Range CCA ..........................100-2000 BCI ..........................

  • Page 6: Health And Safety Information

    HEALTH AND SAFETY INFORMATION 5.1 SAFETY INFORMATION For your own safety and the safety of others, and to prevent damage to the equipment and vehicles, read this manual thoroughly before operating your code reader. The safety messages presented below and throughout this user’s manual are reminders to the operator to exercise extreme care when using this device.

  • Page 7: Technical Description

    TECHNICAL DESCRIPTION 6.1 IDENTIFICATION LCD Display - shows menus, test results and operation tips. Green LED Display - indicates the battery is good and can competently hold a charge. Yellow LED Display - indicates the battery needs charging. Red LED Display - indicates the battery cannot sufficiently hold a charge and should be replaced.

  • Page 8: Unpacking And Checking

    Lay the contents out and check them against the parts shown below. If any part is damaged or missing; please contact the Draper Helpline (the telephone number appears on the Title page) and do not attempt to use the machine.

  • Page 9: Battery Diagnostic Tool Instruction

    BATTERY DIAGNOSTIC TOOL INSTRUCTION 8.1 HOW TO USE Connect the red test clamp with positive battery terminal and black test clamp to the negative battery terminal, the tester will power on automatically. Note: If the battery is below 7.0V, there will not be enough power for the Diagnostic tool to work, press OK key to continue.

  • Page 10: Charging Test

    BATTERY DIAGNOSTIC TOOL INSTRUCTION Test result of the diagnostic tool includes actual cranking voltage and actual cranking time. 3) Charging Test Select the charging test. The diagnostic tool will prompt "RIPPLE TEST" Note: Do not turn off the engine during the test. Turn on/off any electrical appliances in the vehicle during the test.

  • Page 11: Explanation Of Symbols

    EXPLANATION OF SYMBOLS 9.1 EXPLANATION OF SYMBOLS Warning! Read the instruction manual. Do not dispose of WEEE* unsorted municipal waste. - 11 -...

  • Page 12: Disposal

    10. DISPOSAL 10.1 DISPOSAL – At the end of the machine’s working life, or when it can no longer be repaired, ensure that it is disposed of according to national regulations. – Contact your local authority for details of collection schemes in your area. In all circumstances: •...
  • Page 13 NOTES - 13 -...
  • Page 14 NOTES - 14 -...
  • Page 15 NOTES - 15 -...
  • Page 16 ©Published by Draper Tools Limited. No part of this publication may be reproduced, stored in a retrieval system or transmitted in any form or by any means, electronic, mechanical photocopying, recording or otherwise without prior permission in writing from Draper Tools Ltd.
