Makita 6280DWPE Parts Breakdown

Item Part Qty.
No. No. Used
1 125102-2 1 SPEED CHANGE LEVER ASS'Y
2 183795-1 1 HOUSING SET (Incl. 14,15)
4 266130-9 9 TAPPING SCREW BIND PT 3X16
5 232182-2 1 LEAF SPRING
6 417283-9 1 F/R CHANGE LEVER
7 650556-9 1 SWITCH C3NA-1-M1
8 643909-9 1 BATTERY HOLDER
9 251468-5 1 - FLAT HEAD SCREW M6X22
11 125237-9 1 GEAR ASS'Y
12 629819-4 1 DC MOTOR
13 911003-8 2 PAN HEAD SCREW M3X6
14 819001-5 1 MAKITA LABEL
15 183795-1 1 HOUSING SET (Incl. 2,14)
02-05
"
3/8 Cordless Driver Drill
(10MM)
9
10
14
15
Description
SINGLE VAR/REV
5
6
7
8
11
12
13
Item Part
No. No.
ACCESSORIES
10 763185-0
A01 414938-7
A02 DC1804
A03 784636-0
A04 824635-1
A05 194172-2
1
MODEL 6280DWPE
1
2
4
Qty.
Used Description
1 KEYLESS DRILL CHUCK 10
2 BATTERY COVER
1 BATTERY CHARGER
1 +- BIT 2-65
1 PLASTIC TOOL CASE (Incl. 1 Ea
1 SLIDE LATCH SET 186347-7
1 MAKITA LABEL 819143-5)
1 BATTERY PA14
Model 6280DWPE
