Projector Setup

NOTE: MILO Range Pro systems are generally mounted from the ceiling but also can be in a floor
mounted configuration. Both configurations are covered in the following steps
NOTE: If your system setup requires the addition of an Extron DTP DVI 330 TX and 330 Rx switch and
control please reference the Extron Set Up Guide located in the Training & Support folder either on
your desktop or C:/MILO/Training & Support/User Guides.
Floor mounted system
1. Place the projector on the floor approximately 18' (6m) from the projection screen with the projector
lens pointed at the screen. Do not place the projector on a table or any other raised platform.
2. Connect power to the projector
area where the trainees will walk or stand during training.
3. Connect the HMDI cable to the HDMI #1 input
to the computer location. Make sure the cable does not lie where trainees will stand during training.
4. Connect the HDMI cable to the MILO computer
(Figure 1, Item 1). Make sure the cable does not interfere with the
(Figure 1, Item 2)
(Figure 2, Item
HDMI atFigure 1 - PROJECTOR
www.milorange.com
on the projector. Extend the cable
1).
