BPS-1002
NAC Power Extender
Installation Guide
(See Application Guide for additional information)
Rev. 101413
firealarmresources.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BPS-1002 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Mircom BPS-1002

  • Page 1 BPS-1002 NAC Power Extender Installation Guide (See Application Guide for additional information) Rev. 101413 firealarmresources.com...
  • Page 2: Specifications

    BPS-1002 - NAC Power Extender Overview: Mircom BPS-1002 is an extremely cost effective 10 amp remote power supply/battery charger. It may be connected to any 12 or 24 volt Fire Alarm Control Panel (FACP). Primary applications include Notification Appliance Circuit (NAC such as strobes and horns) expansion support to meet ADA requirements.
  • Page 3: Power Supply Specifications

    4. Connect battery to the terminals marked [+ BAT - - ] on the Power Supply Board (battery leads included). Note: If batteries being used in your installation do not fit into the BPS-1002 unit, it is required to install a separate enclosure, UL Listed for appropriate application.
  • Page 4 Cooper Wheelock. *Note: The BPS-1002 will only synchronize horns, horn/strobes and strobes that contain synchronization capability. Contact signal manufacturer for more detailed info. The same synchronization mode must be selected for all outputs.
  • Page 5 For loads connected to “AUX” please refer to battery “Stand-by Specifications” above for ratings. When loads are connected to “AUX” output during alarm condition, the remaining outputs may not exceed 10 amp total alarm current (example: AUX = 1 amp, outputs up to 9 amp). BPS-1002 - 5 - firealarmresources.com...
  • Page 6 The green input LEDs will be off (normal condition). To reset the memory depress the reset button (Fig. 3c, pg. 8). The LED(s) will extinguish. Note: If indicating circuits have been restored, memory reset is not required for normal operation of the unit. - 6 - BPS-1002 firealarmresources.com...
  • Page 7 NEC Power-Limited Wiring Requirements for BPS-1002 Models: Power-limited and non power-limited circuit wiring must remain separated in the cabinet. All power-limited circuit wiring must remain at least 0.25” away from any non power-limited circuit wiring. Furthermore, all power-limited circuit wiring and non power-limited circuit wiring must enter and exit the cabinet through different conduits.
  • Page 8: Maintenance

    Note: Expected battery life is 5 years; however, it is recommended changing batteries in 4 years or less if needed. Addressable Control 2.5 amp per output in alarm Module Trigger Output Total = 10 amp See Note 2 (Supervised) (Non-Supervised) - 8 - BPS-1002 firealarmresources.com...
  • Page 9: Battery Calculation Worksheet

    Current per number of devices. Stand-by: 130mA 130mA BPS-1002 (Current draw from battery) Alarm: 300mA 300mA BPS-1002 Current 130mA 300mA Auxiliary Devices Refer to device manual for current ratings. Alarm/Stand-by Alarm/Stand-by Alarm/Stand-by Auxiliary Devices Current (must not exceed 1 amp) Refer to device manual for current ratings.
  • Page 10: Appendix A - Ul/Cul Listed Compatible Devices For Synchronization

    Appendix A - UL/cUL Listed Compatible Devices for Synchronization A-1 Strobes, Horns and Horn/Strobes Table A-1 below lists Strobes, Horns and Horn/Strobes compatible with BPS-1002 NAC outputs. Gentex: GCS24CR - UL GCCB24PCR / W - UL GEC24-15/75WR - UL GCS24CW - UL...
  • Page 11 Appendix A - UL/cUL Listed Compatible Devices for Synchronization (cont’d) A-1 Strobes, Horns and Horn/Strobes Table A-1 below lists Strobes, Horns and Horn/Strobes compatible with BPS-1002 NAC outputs. Potter/Amseco: CM24CR - UL CSL-1224W-BW - UL/cUL MH-12/24W - UL/cUL SSC8-177R - UL...
  • Page 12: Appendix B - Ul Listed Compatible Devices

    STWC-NG - UL STWC-NR - UL Appendix B - UL Listed Compatible Devices B.1 Four (4) Wire Smoke Detectors Table B-1 below lists four (4) wire smoke detectors compatible with BPS-1002 AUX output. Max Stand-by Alarm Current Smoke Detector/Base Detector Type...
  • Page 13 Appendix B - UL Listed Compatible Devices B.1 Four (4) Wire Smoke Detectors Table B-1 below lists four (4) wire smoke detectors compatible with BPS-1002 AUX output. Max Stand-by Alarm Current Smoke Detector/Base Detector Type Current (mA) (mA) System Sensor 2W-MOD Loop Test/Maintenance Mod.
  • Page 14 Notes: - 14 - BPS-1002 firealarmresources.com...
  • Page 15 Notes: BPS-1002 - 15 - firealarmresources.com...
  • Page 16 (38.1mm) (117.22mm) (117.22mm) (38.1mm) Mircom is not responsible for any typographical errors USA - 4575 Witmer Industrial Estates, Niagara Falls, NY 14305, Canada - 25 Interchange Way, Vaughan (Toronto), ON L4K5W3, 888-660-4655 • fax: 888-660-4113 web site: www.mircom.com IIBPS-1002 K24O...
