SSF1014 CERTIFIED BATTERY BACKUP WITH COMMUNICATION
NOVA FLX L
NOVA FLX L is available in 12 V - 24 V and can be mounted on a wall or in a 19 "rack.
Name, article number, e-number and certificate number
Name
Article number
NOVA 24V 5A
FL01P30024P050-SSF
FLX L
NOVA 24V 10A
FL01P30024P100-SSF
FLX L
About
is mainly used in safety systems where SSF 1014 approved battery backup is required or where the
requirements are higher. Requirements such as better flexibility, more alarm functions, longer backup
operating times or where the battery backup needs to handle higher loads.
The NOVA series is system certified according to SSF1014 together with most systems on the Swedish
market. Milleteknik has the right to sell two different systems on the Swedish market; Sentrion NOVA
The series has communication via RS485 to Sentrion S4, S4 DUO and CISS. Integra. Together with
MOVEO kit (optional) there is RS232 communication with Integra MOVEO and MOVEO XL.
• SSF1014, Alarm class 1-3 approved battery backups / power supply.
• Controlled charging function.
• Qualified battery capacity test.
• Can be supplemented with several different optional cards.
• Mounted on a wall or in a 19 "rack.
• Flexible battery capacity with battery boxes increases backup operating time.
Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille
E-number
Certified according to
5213569
Fulfils the requirements in Alarm Class 4
according to SSF 1014, utgåva 5
5213570
Fulfils the requirements in Alarm Class 4
according to SSF 1014, utgåva 5
2022-10-11
Certificate
number
No20-117
No20-117
www.milleteknik.se

Advertisement

loading
Need help?

Need help?

Do you have a question about the NOVA 24V 5A FLX L and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for milleteknik NOVA 24V 5A FLX L

Summary of Contents for milleteknik NOVA 24V 5A FLX L

  • Page 1 The NOVA series is system certified according to SSF1014 together with most systems on the Swedish market. Milleteknik has the right to sell two different systems on the Swedish market; Sentrion NOVA The series has communication via RS485 to Sentrion S4, S4 DUO and CISS. Integra. Together with MOVEO kit (optional) there is RS232 communication with Integra MOVEO and MOVEO XL.

  • Page 2: Fixed Installation

    REGULATIONS AND CERTIFICATIONS Standards that product (s) meet and are approved for Standards ONE: EN50131-6 SSF: SSF1014 Alarm class 1-4 (burglary alarm) SSF1014, Meets alarm class 3 SSF1014, edition 5 www.milleteknik.se Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille...
  • Page 3 6.0 A 7.5 A Alarm Class 3-4 Imax A (max discharge current) Imax b (max charging current) Imin is always 0 A. Not all devices may be certified, see device certificate. Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille www.milleteknik.se...
  • Page 4 SSF1014 Alarm class 1/2 12 h 72 h SSF1014 Alarm class 3/4 30 h 24 h The table shows the requirements for backup operating time and recharging of batteries for different alarm classes. www.milleteknik.se Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille...
  • Page 5 Indoors, class 1. Ambient temperature: + 5 ° C - 40 ° C. Protection class IPX0 Recommended installation NOVA Series (only 5 A and 10 A) Input voltage 13.6 VDC, 27.3 VDC Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille www.milleteknik.se...

  • Page 6: Power Supply

    Explanation P4:1 P4:2 P4:3 P4:4 POWER SUPPLY Power supply - Technical Data LRS-150-24 NOVA 24V 5A FLX L Info Explanation Output voltage 27.3 V Output current: 0 A - 6.5 A www.milleteknik.se Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille...
  • Page 7 Environment Environmental class 1, indoors. 20% ~ 90% relative humidity Material Powder coated sheet Color Black Cable entries, number Batteries that fit 2 st 12 V 45 Ah Place for fan Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille www.milleteknik.se...

  • Page 8: Spare Parts

    Milleteknik provides support during the product's lifetime, however, no later than 10 years after the date of purchase. Switching to an equivalent product may occur if Milleteknik deems that repair is not possible. Support may be added (at Millteknik's desrection) after the warranty period has expired.
  • Page 9 Backup operating times 24 V units - without battery box Medium current 7.2 Ah 14 Ah 28 Ah 45 Ah Loading Backup operating time (approx.), Minutes 0.5 A 1650 2350 1460 Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille www.milleteknik.se...
  • Page 10 Loading Backup operating time (approx.), Minutes 0.5 A 9408 12972 11760 5856 7872 7320 3672 4548 4590 2365 2670 2945 1577 1780 1960 1500 1558 1800 10 A 1140 1246 1410 www.milleteknik.se Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille...
  • Page 11 2022-10-11 Medium current 180 Ah 200 Ah 225 Ah 12 A 1038 1200 14 A 1055 16 A 18 A 20 A Milleteknik AB, Ögärdesvägen 8 B, 433 30 Partille www.milleteknik.se...
