Summary of Contents for D-Link DES-F1026P-E
- Page 1 PRODUCT QUICK INSTALLATION GUIDE DES-F1026P-E 26-Port 250m Long Reach PoE Switch with 24 Fast Ethernet PoE+ Ports and 2 Gigabit Uplink Ports with 1 Combo SFP/RJ45 Port...
- Page 2 1.1 Package Contents The package contains the following items: PoE Switch • Power Cord • 19” Rack Mounting Kit • Quick Installation Guide • 1.2 Safety Instructions Use the following safety guidelines to ensure your own personal safety and to help protect your equipment from potential damage.
- Page 3 1.4 Product Connection Diagram FRONT PANEL...
- Page 4 1.5 Product Installation The DES-F1026P-E switch can be installed on a desktop, shelf or mounted in a standard 19-inch rack. To install the switch in a rack, attach the supplied mounting brackets to the side of the switch and fasten the brackets to the sides of the switch using the screws from the switch mounting kit.
- Page 5 1.7 Product Specifications Extend: Supports long reach PoE delivery, up to 250m. (Cat 5 or better cabling is recommended) VLAN: Isolates ports from each other. Adds security and improves network performance by constraining broadcast traffic. Switch Modes QOS: Introduces application prioritisation. Traffic with higher priority (e.g.
